17.5 Assignment list
View inputs / control outputs
Indication
Left Right
In 1 0/1
In 2 0/1
In 3 0/1
In 4 0/1
In 5 0/1
In 6 0/1
In 7 0/1
In 8 0/1
In 9 0/1
In 10 0/1
In 12 0/1
In 13 0/1
In 14 0/1
In 15 0/1
In 16 0/1
In 17 0 ..255
In 18 0 ..255
In 19 xxx
In 20 xxx
In 21 xxx
In 22 0 ..255
In7 9 0/1
In7 10 0/1
In7 18 0/1
In7 19 0/1
Wash pump (DV 80.2 / DV 200.2)Programm Start f. Waschpumpe
Ou 1 0/1
Ou 2 0/1
Ou 3 0/1
Ou 4 0/1
Ou 5 0/1
Ou 6 0/1
Ou 7 0/1
Ou 8 0/1
Ou 9 0/1
Ou 10 0/1
Ou 11 0/1
Ou 12 0/1
Ou7 4 0/1
Ou7 5 0/1
Datei:BA_DV80.2_120.2_125.2_200.2_200.2PW_9625769_EN_2002-10.doc
MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121
Input / output / other
Hood closed
Boiler level
Leak water switch floor
not occupied
not occupied
Hall-sensor ADT (vacuum dosing)
rnot occupied
Level rinse aid (option)
Level detergents (optin)
not occupied
Threshold tank level.1
Threshold tank level.2
Threshold tank level.3
Tank level. 4 (Option)
Without function
Without function
Boiler temperature in °C or °F
Tank temperature in °C or °F
Tank level (1 mm unit)
Without function
Level switch in water softener inlet chamber
"No salt" switch
not occupied
not occupied
(DV 120.2 / DV 125.2 / DV 200.2 PW)
Booster Pump
Drain pump
Rinse aid – dosage pump
Detergent – dosage pump
Operation indicator
Filling valve
not occupied
Boiler heating
Tank heating
not occupied (DV 80.2 / DV 200.2)
Speed S5
(DV 120.2 / DV 125.2 / DV 200.2 PW)
not occupied (DV 80.2 / DV 200.2)
Speed S5
(DV 120.2 / DV 125.2 / DV 200.2 PW)
Booster pump water softener
not occupied
