Operating instructions
Dishwashing machine
EcoStar 545 D-M
TRANSLATION OF THE "ORIGINAL OPERATING INSTRUCTIONS"
The original operating instructions can be downloaded from: https://partnernet.meiko.de
1/44
9662798
Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc
Update: 2015-09-29
W e reserv e the right to change execution and construction!
MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121

Advertisement

Table of Contents
loading

Related Manuals for Meiko FV 28 G-M

Summary of Contents for Meiko FV 28 G-M

  • Page 1 TRANSLATION OF THE "ORIGINAL OPERATING INSTRUCTIONS" The original operating instructions can be downloaded from: https://partnernet.meiko.de 1/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc Update: 2015-09-29 W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 2: Table Of Contents

    Tips for self-help in the case of faults Staff training Authorized user of this documentation 2/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 3 19.2 Dosing units 19.3 Maintenance plan Environmentally acceptable measures, disposal of the installation Documentation 3/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 4: Introduction And General Information

    Dear Customer, We are delighted about the confidence you have shown in our products. It is very important to us that you should obtain significant use from MEIKO products and that they should make your work easier. If you follow the instructions in this document carefully, your dishwashing machine will al- ways give you total satisfaction and will have a long service life.

  • Page 5: Storage

    Please provide the following information on any query and/or when ordering spare parts: Type: This information can be found on the plate. 5/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 6: Explanation Of The Safety Symbols Used

    This dishwashing machine is intended solely for use in a commercial environment. 6/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 7: Ec-Declaration Of Conformity

    Costruzione / Jefe de la sección de desarrollo y diseño / Chef Ontwikkeling-Constructie 7/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 8: General Safety Information

    IMPORTANT! ty of the wash and hygiene is your responsibility. 8/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 9: Basic Safety Measures

    The appliance must not be used to transfer waste water from other sources into the drain. ATTENTION! 9/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 10: Delivery, Shipping, Installation And Assembly

    Check that the delivery is complete immediately after receiving it by comparing it to MEIKO’s contract confirmation and/or the delivery note. 10/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 11: Transport, Installation And Assembly

    ATTENTION! An engineer from your local MEIKO Service Centre can install the appliance at the correct point and connect the tables - upon request. An engineer from your local MEIKO Service Centre can install the appliance at the correct point and connect the tables - upon request.

  • Page 12: Operating Conditions

    The wiring diagram is behind the front panel, resp. front cladding of the appliance. The enclosed wiring diagram must remain in the appliance. 12/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 13: Requirements For The Fresh Water Connection

     Switch the machine off completely via the on-site power disconnection device. 13/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 14: Chemicals For The Operation Of The Appliance

     Please also read the chapter on “General safety instructions ".  Commissioning and instructions will be provided by technicians specially trained by Meiko. The operator may only use the installation after training has been pro- vided. 14/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH &...

  • Page 15: Washing With Dish-Washer

    Cycle interruption Table 1; Program key function / items to be washed 15/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 16: Preparation For Washing And Rinsing

    Short wash times with baskets which are not overloaded are much more economical 16/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 17: Shutting Down The Dishwasher

    ATTENTION! 17/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 18: Refilling Of Detergent

    Never use cleaning equipment that you have used previously by non-stainless steel to avoid external corrosion. 18/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 19: Scaling

    Short Programming Instructions. 19/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 20: Capacity Of The Built-In Water Softening Device

    If the salt remains in the wash tank for a lengt hyperiod, this can result in corrosion and even pitting corrosion in the bottom of the tank. 20/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 21: Basic Information On The Appliance

    Both method makes it possible to achieve disinfection levels higher than the standard (e.g. in hospitals). 21/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 22: Noise Level

    (e.g. pacers, defibrillators) by maintaining a safety distance of 30 cm (dis- tance of the field source to the implant). 22/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 23: Tips For Self-Help In The Case Of Faults

     Detergent or rinse aid product not suitable  Temperatures too low < 40°C 23/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 24: Staff Training

    The works described in this booklet (chapter 17 - 21) may only be carried out by specialists of the manufacturer, the responsible agency or an authorized dealer. 24/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 25: Settings / Modifications / On-Site Adaptation

    “accept” key to save it. The next value will then flash and will be the only one visible. 25/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 26: Service Level

    You are now at the current level. You can leave this level by pressing the “0” key. 26/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 27 You can leave this level by pressing the “0” key. The ventilation will be interrupted off. Should the ventilation process be insufficient, repeat the process. 27/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 28 You are now at the current level. You can leave this level by pressing the “0” key. 28/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 29 Display: input not set You can leave this level by pressing the “0” key. 29/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 30 P104, P105, P218, P219, P224, P225, P321, P322, P326, P327. See 17.4 for list of parameters 30/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 31: Parameter List

    It is possible to shut off communi- cation via IR interfaces. (0) 31/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 32 2 - Energizing as final rinse 3 - Energize as wash pump 32/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 33 0 ...90 10 sec. Only with disinfection machine no.4 temperature in parameter 201 33/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 34: Assignment List View Inputs / Control Outputs

    No leak water Leak water switch condition: Leak water switch must not have operated. 34/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 35: Rinse Program Parameter Update: 01.05.2009

    The dosage times will be adapted to the rinse time, so that the correct concentration remains if the rinse time is modified. 35/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 36: Operating Errors

    (only if there is a built-in warning sys- tem). 36/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 37 The user must start the regeneration. (empty tank, add salt!) Table 2: Information displays 37/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 38: Error Messages And Troubleshooting

    Contactor sticking high(>95°C) Incorrect sensor / defective sensor Check sensor / cable 38/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 39 39/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 40: Maintenance

     Hose lines and dosing units must always be rinsed out with warm water. 40/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 41: Maintenance Plan

    Tighten all electrical connections Check tank and boiler heating Check thermostat and stop switch 41/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...

  • Page 42: Environmentally Acceptable Measures, Disposal Of The Installation

    Installation drawing / technical sheet Technical data sheet Wiring diagram / Programming instructions 42/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
  • Page 43 Operating instructions EcoStar 545 D-M 43/44 9662798 Datei:BA_EcoStar545D-M_9662798_EN_2009-05.doc W e reserv e the right to change execution and construction! MEIKO Maschinenbau GmbH & Co. KG, Englerstr. 3, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1121...
