Step
3 Configure the following parameters for each session:
• Session Name
Enter a unique, descriptive identifier for the session. This name can have a maximum of 32
characters.
• Virtual Path ID (VPI)
Enter the value (from 0 to 4,095) provided by the service provider. The number identifies the virtual
path that transports ATM cells between the modem and the service provider. This value must match
the virtual path identification (VPI) value the service provider uses for this connection. Default is 0.
• Virtual Channel ID (VCI)
Enter the value (from 32 to 65,535) provided by the service provider. The number identifies the virtual
channel for this session that transports ATM cells between the modem and the service provider. This
value must match the virtual channel identification (VCI) value the service provider uses for this
connection. Default is 35.
• Encapsulation
Select the encapsulation type as indicated by the service provider. The options are:
– LLC/SNAP—Logical Link Control allows multiple protocols to be run over the session. Default is
LLC/SNAP.
– VcMux—Virtual Channel Multiplexer-based encapsulation allows one protocol to be run over the
session.
4 Click Apply to add the new RFC1483-Bridged session to your session list on the WAN Configuration
page.
