A R E
DD OUTER NTRIES
A router provides a defined path from one host or network to a destination host or network. This type of route is
manually entered as a fixed path, as contrasted to a dynamic route which is automatically determined and learned
(e.g., RIP). If the next gateway for network traffic is unknown, a router will be its default path. Adding a system
default gateway creates a default router entry in the Router table.

IP Interface

Step
1 Select Configuration|Advance|Router|IP Interface to access the IP Address Table page
2 Click Add a New Service. Refer to
Note: Configure LAN in Routing Mode to make WAN Routing session function properly.
MM702G2-W-UM-03
Action
Figure 6-19. IP Interface
"Configure a New WAN Session" on page
Chapter 6: Configuring Advanced Features
5-15.
(Figure 6-19).
6-21
