Chapter 2: Accessing the Web Interface for Modem Management
Step
5
Enter an IP Address and Subnet Mask that places the management PC on the same subnet as the
modem. Use an IP address in the range of 192.168.0.2 to 192.168.0.254.
6
Click OK to close the TCP/IP Properties dialog.
7
Click OK to close the Network dialog.
8
Click OK to restart the computer.
S
U
W
B
ET
P THE
EB
To access and view the modem Web pages, set up features for the Web browser. The Web browser must have
cache settings enabled to allow the Web browser to compare its cached Web page against the modem Web page
every time it is accessed, providing current information. Also, it is preferable to disable proxies. (The example below
shows setup for the Internet Explorer Web browser; instructions for other Web browsers may differ slightly.)
Step
1
Open the Web browser.
2
On the menu bar, click Tools|Internet Options to open the Internet Options dialog
3
In the Temporary Internet Files section of the dialog, click Settings.
4
Select Every visit to the page, then click OK. (This sets enables cache settings.)
2-2
ROWSER
Figure 2-2. Internet Options
Action
Action
(Figure
2-2).
MM702G2-W-UM-03
