S
PECIFICATIONS
The MM702G2-W is a 1-pair/2-pair SHDSL modem that takes advantage of G.shdsl technology by offering fixed and
rate-adaptive communication at equal rates going both upstream and downstream until 4608 Kbps is reached. In
addition, the modem also provides sessions for precise control of security, performance and management of users
and resources per session; allowing Service Providers to offer additional services and class of service for Internet
access, private ATM networks or connections to application servers like video servers or voice gateways. Also
provided is self-installation for non-technical users.
O
VERVIEW
• The MM702G2-W provides fixed-rate or rate-adaptive, symmetric G.shdsl transmission up to 4.608 Mbps
• PPPoE (with TCP MSS Clamp support)
• PPP over ATM (RFC 2364)
• RFC 1483 bridging over ATM AAL5 (RFC 2684)
• RFC 1483 routing over ATM AAL5
• Unnumbered IP
• Spanning Tree
• IGMP v1/2
• SNTP Client
• Firewall/Security
• Intrusion Detection
• Traffic Filtering
• Source and destination MAC Address Filtering
• Eight simultaneous WAN sessions
• Support for point-to-point LAN extension (Bridging & Routing)
• DHCP (client and server) for sending and receiving dynamic IP addresses, DHCP default gateway, and DNS
server
• DHCP Relay
• DNS Relay
• NAT for IP address translation
• Web interface HTTP upgrade for modem software updates
• Static Routing
• RIP versions 1 and 2 for dynamic IP routing information exchange
• Easy to use WEB Interface on Ethernet and WAN Interface
• SNMP v1/2 Agent
• 10/100Base-T LAN interface with MDI/MDI-X switch
• Front panel LEDs for troubleshooting and monitoring LAN and SHDSL connections
• PAP and CHAP for PPP login name and password authentication
• ATM Quality of Service selection
• Statistics for monitoring network traffic on Ethernet and WAN sessions
• F4/F5 OAM support
• Reset Button (Reset/Factory Defaults)
• Proxy ARP
