C N
ONFIGURE A EW
You can configure up to 8 total PPPoA, PPPoE, 1483-Bridge, and 1483-Router sessions for the modem. From the
WAN configuration page
Step
1 Select Configuration|WAN to access the WAN Configuration page
2 To add a new session, choose one of the following protocols from Create a new service.
• RFC 1483 bridged if the modem forwards packets based on RFC 1483 Bridging.
• RFC 1483 routed if the modem routes packets based on RFC 1483 Routing.
• PPPoA routed if the modem establishes PPP sessions over ATM with the service provider and routes
packets based on IP addresses.
• PPPoE routed if modem establishes PPP sessions over Ethernet with the service provider and routes
packets based on IP addresses.
• IPoA routed if the modem establishes IP sessions over ATM with the service provider and routes
packets based on IP addresses.
F4 and F5 OAM are enabled on default PVC (0/35) and on every new PVC that is created.
MM702G2-W-UM-03
WAN S
ESSION
(Figure 5-12), define the parameters for each session.
Figure 5-12. WAN Configuration
Chapter 5: Configure LAN, WAN, and SHDSL
Action
(Figure 5-12).
5-15
