ADC MM702G2-W V5.x User Manual page 140

Chapter 6: Configuring Advanced Features
Step
2 Enter the following parameters to enable STP for bridging sessions:
– Spanning Tree
Select True to activate the STP for all RFC 1483-Bridge sessions and LAN Port. False turns off STP
for all modem bridging sessions and LAN Port. Default is False.
– Priority
The modem STP priority (how centrally located this bridge is) in the network. A lower number
indicates a more centrally located bridge. The valid priority range is 0 to 65535. A priority of 32768 is
the default value. Default is 32768.
– Forward Delay
The time interval in seconds that should be waited until the state of an interface can change. This
delay prevents interface states from changing so rapidly that STP cannot keep up with the current
network topology and therefore cannot efficiently managing bridging. Default is 15.
– Hello Time
The time interval in seconds at which the modem should send STP packets. Default is 2.
– Maximum Age
The time interval in seconds after which Spanning Tree entries that are not relearned are deleted
from the bridging table. Default is 20.
3 Click OK to add the parameters or click Reset to keep the current settings.
6-42
Action
MM702G2-W-UM-03
