Chapter 6: Configuring Advanced Features
Step Action
2 To create a New VLAN configuration, do the following. By default, Name of Default VLAN is DefaultVlan,
Default FDB Name is DefaultFdb, Default VLAN ID is 1 and Ethernet and Bridged WAN interface are part
of Untagged ports.
a. On the VLAN Configuration Page (Figure 6-35 on page 6-36), click VLAN Configuration.
Figure 6-36 is displayed.
Figure 6-36. VLANs
MM702G2-W-UM-03 6-37
