Step
21 On the Bridge Interface Configuration page
displayed.
22 Configure the following parameter:
• Traffic Classes – Valid values are 0-8 Default is 8.
• User Priority to Regenerated Priority Map – Valid values are 0 to 7 Defaults are 0-7 (depending on
the User Priority).
• Regenerated Priority to Traffic Class Map – Valid values are 0 to 7 Defaults are 0-7 (depending on
the Regenerated Priority).
23 Click OK to add the parameters or click Reset to keep the current settings.
MM702G2-W-UM-03
Chapter 6: Configuring Advanced Features
Action
(Figure 6-33 on page
Figure 6-34. Priority Map
6-34), click Priority Map. Figure 6-34 is
6-35
