Note: 51-pin GLENAIR Cable Adapter features resettable fuses on pins 5, 6, 7, 8, 9, 11, 13 and 15. These protect
debug signals against overcurrent and cycle back to a conductive state after the excessive current fades away.
Signals on pins 19, 21, 23, 25, 26, 27, 29, 31, 35, 37, 39, 41, 43, 45, 47, 49 and GND are protected via 47 ohm
serial resistors.
The adapter connects to the target via a 51-pin GLENAIR connector (for example GLENAIR - M83513/02-GN).
A target should feature a matching part (for example GLENAIR - M83513/01-GN).
