  • Page 1 On-Chip Analyzer V1.1 User Manual...
  • Page 2 This document and all documents accompanying it are copyrighted by iSYSTEM AG and all rights are reserved. Duplication of these documents is allowed for personal use. In all other cases, written consent from iSYSTEM is required. Copyright  iSYSTEM AG.

  • Page 3: Table Of Contents

    Package content .......................... 3 Specifications ..........................4 Operation ............................. 5 Device overview ........................5 Device description ........................5 Connecting the iC5000 to the target hardware ............... 7 Grounding wire ........................7 Power Supply ........................7 Debug Adapter ........................7 Accessories ..........................10 I/O Module ..........................

  • Page 4: Introduction

    Introduction The iC5000 BlueBox On-Chip Analyzer is a hardware and software platform designed for debugging and testing a wide range of embedded microcontroller platforms that are based on a variety of processor architectures. Functionality can be further extended with the addition of the I/O Module, enabling the synchronous capture of analog and digital signals in parallel to trace information.

  • Page 5: Important Safety Notice

    Use this instrument only for its intended purpose as specified by this manual to prevent potential hazards. Use included power cord and power supply The enclosed power supply has been approved for use by iSYSTEM. Please contact iSYSTEM if you need to consider an alternative power. Use grounding wire Prior to applying power to either the BlueBox or the target, connect the device and the target system together with the included grounding wire.

  • Page 6: Package Content

    Package content The standard iC5000 order is delivered with the following components: iC5000 Base Unit including 25 cm 40-pin ribbon cable Power supply pre-assembled DTM module Ordering code: Ordering code: Ordering code: IC50000 + IC50020 IC50020-25 IC30000-PS USB 2.0 cable...

  • Page 7: Specifications

    10kΩ pull-up resistor TDO input 10kΩ pull-down resistor TMS and TDI debug signals 10kΩ pull-up resistor RESET 1kΩ pull-up resistor, buffer-driven to prevent current flow into an unpowered iC5000 from a powered target board TAR_VREF (target reference voltage) pin 100kΩ input impedance...

  • Page 8: Operation

    Operation Device overview Device description The top face of the iC5000 features two key areas; the DTM connectors A and the indicator lights B:  A – The Debug Trace Module (DTM) provides two connectors, marked #1 and #2. These connectors are the interface to the target microcontroller.
  • Page 9  G – USB 2.0 Socket It is recommended to use the supplied USB 2.0 cable delivered with your iC5000 as it has been confirmed to fulfil the maximum USB 2.0 transfer rate. Use of alternate cables must be undertaken at your own risk.

  • Page 10: Connecting The Ic5000 To The Target Hardware

    BlueBox hardware, the target or both. Power Supply The iC5000 unit accepts a wide input voltage range from 10V to 24V DC, thus enabling the BlueBox hardware to work also with a 12V or 24V vehicle battery.
  • Page 11 The debug adapter should be connected to one end of the 25-cm, 40-pin ribbon cable (included in your iC5000 delivery), with the other end being connected to the DTM #1 socket as described below: Connect the 40-pin ribbon cable connector to the iC5000 DTM #1 socket.
  • Page 12 When fitting the ribbon cable to the iC5000, the connector must always be guided towards the iC5000 front panel with the red (edge) wire on the side of the ‘#1’ or ‘#2’ marking. Ensure the orientation key of the connector aligns with the notch on socket of the iC5000. Carefully press the cable connector straight down, keeping the connector parallel to the upper face of the iC5000, until the side latches lock.

  • Page 13: Accessories

    Accessories I/O Module The functionality of the iC5000 can be extended through the use of the available I/O modules. Both provide monitoring and manipulation of analog and digital signals. Ordering Code Description IC50011 I/O Module (sync, trig out, 2x2 Analog In/Out, 2x8 Digital In/Out)

  • Page 14: Standard Debug Adapters

    Standard debug adapters Various debug adapters are available to connect the iC5000 to a wide range debug connectors as commonly found on microcontroller development boards. Ordering Code Description 20-pin 2.54mm ARM Debug Adapter IC50111-1 14-pin 2.54mm ARM Debug Adapter IC50112 20-pin 1.27mm AMP Cortex Debug Adapter...

  • Page 15: Declarations

    Schwabhausen, 21. March 2017 iSYSTEM AG f. Informatiksysteme - Carl-Zeiss-Str. 1 - 85247 Schwabhausen - USt-IdNr. DE128231221 Vorstand: Erol Simsek, Werner Fischer, Martin Gröstenberger - AG: München HRB 148751 - St-Nr.: 115/120/30027 Bank: Sparkasse Dachau BLZ 70051540 Account 904045 - IBAN: DE82700515400000904045 - BIC: BYLADEM1DAH...

  • Page 16: Technical Support

    While iSYSTEM reserves the right to make changes to its products and/or the specifications detailed herein, it does not make any representations or commitments to update this document.
