CONTROL HORN INSTALLATION.

Control horn install as same as method of
aileron wing. See pictures below.
Remove covering.
Elevator control horn.
5) Slide the vertical stabilizer back in
place. Using a triangle, check to ensure that
the vertical stabilizer is aligned 90º to the hori-
zontal stabilizer.
Vertical
Stabilizer. Elevator control horn.
Horizontal 90º
Stabilizer.
Rudder control horn.
C/A glue.
6) When you are sure that everything is
aligned correctly, apply C/A glue to fix them.

PUSHROD INSTALLATION.

Pushrod install as same as method of
pushrod wing. See pictures below.
C/A glue.
Pushrod.
Pushrod.
