Attach the string to the servo lead and
carefully thread it though the wing. Once you
have string the lead throught the wing, remove
the string so it can use for the other servo
lead. Tape the servo lead to the wing to prevent
it from falling back into the wing.
String.
www.seagullmodels.com
String.
Electric wire.
Pull.
Electric wire.
Secure the servos with the screws pro-
vided with your radio system.
Electric wire.
Plastic Tape.
Repeat the procedure for other wing
haft.

AILERON CONTROL HORN INSTALLATION.

1) Aileron control horn:
Mix a small amount of 30 minute epoxy and
lightly coat the inside of the hole in the aileron
and the 3x45mm control horn screw.
Wing.
2) Thread the screw (insert the washer) in
to the hole from the top of surface. Wipe away
any excess epoxy on the wing and screw with
rubbing alcohol and a paper towel. Screw the
M3 nut (insert the washer) in place as shown.
Alllow the epoxy to fully cure.
3x45mm.
Aileron.
5
