Section 3-Installation
Ground the KSU
Extend Earth Ground into the KSU(s) using #10AWG wire. Terminate the grounding wire onto the
ground lug provided there. A "known good" earth ground must be connected. Examples of good
earth grounds are:
• Cold water pipe - where the pipe is known not to have plastic or PVC insulators in-line.
• Ground Rod - where the grounding rod is known to meet local electrical specifications for
grounding rod installation. The grounding rod in the photo is 2.5m (10ft) long.
Page 3-8
