Section 2-System Design

Configuration Flexibility

The Emerald ICE can be configured with single or dual cabinets.
• Minimum (612): 6 CO lines + 10 digital +2 analog stations (single cabinet)
• Maximum (1232): 12 CO lines + 22 stations + 10 SLT (single cabinet)
...or (1628): 12 CO lines + 4VoIP channels + 22 stations + 6 SLT (single cabinet)
• Growth with second cabinet: can be expanded to (1840), including 18 CO lines + 22 sta-
tions + 18SLT...
...or (2464), including 24 CO lines + 46 stations + 18SLT
...or (2852), including 24 CO lines + 4 VoIP channels + 46 stations + 6 SLT
...or (4052), including 12 CO lines + 24 T1/PRI channels + 4 VoIP channels + 46 sta-
tions + 6 SLT Only one VoIP gateway is allowed in cabinet 1.
• Only one 6CO board installation is allowed when T1/PRI is equipped in 2nd Cabinet.
The following combinations with different configurations can be generated:
1. First cabinet - Maximum: equipped with 7 boards (including VAA/IVM on CCB) CCB +
(610+2)(6CO+10EKT+2SLT) + 6CO + 12EKT + 4SLT + 4SLT + VoIP gateway .
Possible configurations for cabinet-1 are shown below.
Configuration
(CO/Extension)
612 (Default)
616
620
624
628
632
1212
1216
1220
1224
1228
1232
Page 2-22
Cabinet-1 Configurations
MSU
612,i.e. 12EKT
6CO Board
6CO, Board
(6CO)
10EKT, (12EKT)
2SLT)
1
1
1
1 1
1 1
1 1
1 1
1 1
1 1
1 1 1
1 1 1
1 1 1
4SLT Board VoIP Gateway
(4SLT) (4 Channels)
1
2
1
2
1
2
1
2
