Section 2-System Design
UCD Overflow: 4 digits max.
Record Digits for Voice Recorder function: 4 max.
Delete Digits: 4 digits max.
Suffix for transferred calls: 2 max.
CO Line Loop Current sensing: Interrupt programmable from 50ms to 2500ms.
Paging: 8 Internal Page Extension Groups; 1 External Page Port; 1 Internal All Call; 1 System
(Internal/External) All Call;
Speed Dialing: 1000 total bins, dynamically allocated.
200 bins at default allocated for system-wide use.
20 bins at default allocated for extension use (extensions 401-446 only) (50
possible per extension)
16 digits maximum per bin.
Last Number Redial: 16 digits per station
Save Number Redial: 16 digits per station
User Saved Number (Memo Pad): 16 digits per station
Callback request per station: 1
Camp On by a busy station: 1
Stations Camped on to a station: 1
Stations Camped on to a busy line: 1
Message - Executive Notification: 6 preprogrammed;1 personal per station
Message - Executive Preprogrammed: 6 preprogrammed; 1 personal per station
Message Waiting: 40 simultaneous maximum per system (does not affect VM message indi-
cations)
Name in Display: 1 per station, 7 characters max.
Class Of Service (COS): 10 (0-9) per Day, 10 (0-9) per Night
Toll Restriction To/From Tables: 100 Tables per tenant, 10 digits per entry, Day and
Evening COS assignable per entry per CO Line and Extension.
Forced Verified Account Codes: 600 codes, 2-8 digits max., each assigned a COS.
Call Pick Up Groups: 8 Extension Groups.
Station Lock Password: 4-8 digits per extension.
DB Programming Password: 8 digits ("________" at default).
System Reminder Alarm: 8 time settings per Tenant Group.
Station Alarm: 1 per station repeating or one time.
Ring Schemes: 8
Distinctive Ring Tones: 8 per station.
External Call Forward: Via Extension Call Forward settings.
