Section 2-System Design

Modem Module

The Modem Module is a self-contained integrated modem unit that is installed at J5 and J6 in the
lower left corner of the CCB. The integrated Modem Module allows the servicing Telephone Com-
pany to access the telephone system programming and remote maintenance utilities from an off-
site location (password verification required).
When installed, the servicing technician uses the RMP and a modem (in the PC) to place a call to
the site where the Emerald ICE is installed. If one of the voice processing systems are installed,
routing to the modem extension is automated. Otherwise the person who answered this data call
must transfer the call to Extension 400 (Default). Once the modems have established the data
connection, RMP may be used to perform all servicing operations.
Page 2-10
