Tadiran Telecom Emerald ICE Quick Installation Manual page 48

Section 3-Installation
KSU Components and Installation
The Key Service Units (KSU) are shipped in their own protective master carton and contain the fol-
lowing components:
KSU1
• 1 Mounting Template
• 1 System Installation & Maintenance Manual (this book)
• 1 Quick Start-up Guide
• 1 Pocket Guide
• Standard 612 Board equipped with 6 CO Line ports 10 digital extension ports, Two Analog
Device ports/Door Phone ports and 1 CO Line PF (Power Failure) port.
• Standard CCB (Central Control Board)
• 1 hardware packet
KSU2
• 1 mounting template
• 1 Expansion Cabinet equipped with Base Board
• 1 hardware packet
Open the carton(s) and verify that all items are complete and undamaged. Remove all packing
material and store for future use in the event that return shipment is required.
Mounting the KSU
Follow these instructions to mount the KSU.
1. Select a suitable location for the KSU1 considering that the expansion (KSU2) may be
installed at the same time or sometime in the future. KSU1 and KSU2 may be
mounted such that they are side-by-side or mounted one above the other. The ventila-
tion and mounting provisions of each KSU allow them to be mounted horizontally or
vertically. Refer to the pictures for examples of how the KSU(s) may be mounted.
Page 3-6
