Emerald ICE Quick Installation Guide
17. Observe the System Status LED on each KSU next to the power switch. This LED fol-
lows LED DA2 on the CCB (Central Control Board) and indicates the status of the
main system processor. During the first power-up sequence (Cold-Start strap moved
to "Normal" position), default data (factory program) is loaded. A series of flash rates
occur during this process. When default is successfully loaded or whenever the sys-
tem becomes functional following a power failure, the CCB Heart-beat LED and Sys-
tem Status LED maintains a consistent fast flash rate.
Page 3-3
