A.4.2 Conduit Mounting Restrictions (Rear Entry without Shroud)
See
A.4.3 Conduit Mounting Restrictions (Rear Entry with Shroud)
See
Operations Guide
Figure A-7
for the conduit mounting restrictions (rear entry without shroud).
Figure A-7. Conduit Mounting Restrictions (Rear Entry without Shroud)
Figure A-8
for the conduit mounting restrictions (rear entry with shroud).
Figure A-8. Conduit Mounting Restrictions (Rear Entry with Shroud)
1/2" Conduit
Add
Connector
Spacer
Here
(Not Provided)
1/2" Conduit
(Not Provided)
Add
Spacer
Here
930796N
Mounting the Intercom
Network Cable Entry Restrictions
Network
Cable
(Not Provided)
1/2" Conduit
Connector
(Not Provided)
1/2" Conduit
(Not Provided)
Network
Cable
(Not Provided)
CyberData Corporation
93
