Web Page Item
Backup SIP User ID 2
Backup SIP Auth ID 2
Backup SIP Auth Password 2
Remote SIP Port
Local SIP Port
Outbound Proxy
Outbound Proxy Port
Disable rport Discovery
Re-registration Interval (in seconds)
Unregister on Boot
Keep Alive Period
RTP Settings
RTP Port (even)
Nightringer Settings
Enable Nightringer
Operations Guide
Table 2-13. SIP Configuration Parameters (continued)
Description
Specify the SIP User ID for the second backup SIP Server. This parameter
becomes the user portion of the SIP-URI for the device's extension on the
second backup SIP server. Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the second backup SIP server. This
parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.
Specify the Authenticate Password for the second backup SIP server. This
parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.
The Remote SIP Port is the port number the device will use as the
destination port when sending SIP messages. The default Remote SIP
Port is 5060. The supported range is 0-65536. Enter up to 5 digits.
The Local SIP Port is the port number the device will use to receive SIP
messages. The default Local SIP Port is 5060. The supported range is 0-
65536. Enter up to 5 digits.
Enter the Outbound Proxy address as an IPv4 address in dotted decimal
notation or a fully qualified domain name (FQDN). When an IP address is
configured, the device will send all SIP messages to this IP address.
When an FQDN is configured, the device will run DNS NAPTR, SRV, and
A queries on the FQDN to resolve an IP address to which it will send all
SIP messages. This field can accept entries of up to 255 characters in
length.
The Outbound Proxy Port is port number used as the destination port
when sending SIP messages to the outbound proxy. A value of 0 will
default to 5060. The supported range is 0-65536. Enter up to 5 digits.
Disabling rport Discovery will prevent the device from including the public
WAN IP address and port number in the contact information that is sent to
the remote SIP servers. This will generally only need to be enabled when
using an SBC or SIP ALG in conjunction with a remote SIP server.
The SIP Re-registration interval (in seconds) is the SIP Registration lease
time, also known as the expiry. The supported range is 30-3600 seconds.
Enter up to 4 digits.
When enabled, the device will send one registration with an expiry of 0 on
boot.
The minimum time in milliseconds between keep-alive packets sent for nat
traversal. A value of 0 will disable keep alive packets.
Specify the port number used for the RTP stream after establishing a SIP
call. This port number must be an even number and defaults to 10500.
The supported range is 0-65536. Enter up to 5 digits.
When Nightringer is enabled, the device will attempt to register a second
extension with the SIP server. Any calls made to this extension will play a
ringtone (corresponds to Night Ring on the Audiofiles page). By design,
it is not possible to answer a call to the Nightringer extension.
