CyberData 011186 Operation Manual page 73

2. On the Configure Device page, enter values for the parameters indicated in
Note
Web Page Item
Serial Number
MAC Address
Version
Device Name
Addressing Mode
IP Address
Subnet Mask
Default Gateway
Command Port
Send Events
Event IP Address
Event Port
Energize Time
DST
DST Start
DST End
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-21. DSR Page Configure Device Parameters
Description
Displays the serial number of the door strike relay.
Displays the mac address of the door strike relay.
Displays the firmware version of the door strike relay.
Displays the name of the door strike relay. The default name is "LOCK,"
followed by the 9 digit ASCII serial number. The maximum name length is
13 characters. The unit will always respond to its default name.
Determines whether an IP address will be manually assigned through
Static mode or dynamically assigned through a DHCP server.
Displays the IP address of the door strike relay.
Displays the subnet mask of the door strike relay.
Displays the default gateway of the door strike relay.
This shows the port on which the door strike relay sends status packets to
the device (defaults to 49999).
When enabled, events can be sent to the associated device.
The IP address of the associated device.
This is the port by which the door strike relay receives commands
(defaults to 59999).
This is the number of seconds that the relay will be energized.
Allows you to either enable or disable the Daylight Savings Time feature.
Sets the Daylight Savings Time starting time in the following format:
M3.2.0/02:00:00
M3 is the third month (March).
.2 is the second occurrence of the day in the month.
.0 is Sunday.
/02:00:00 is the time.
Note: When the occurrence is set to 5, the final occurrence of the day in
the specified month is used.
Sets the Daylight Savings Time ending time in the following format:
M11.1.0/02:00:00
M11 is the eleventh month (November).
.1 is the first occurrence of the day in the month.
.0 is Sunday.
/02:00:00 is the time.
Note: When the occurrence is set to 5, the final occurrence of the day in
the specified month is used.
930796N
) in the following table shows which web page items will be defined
.
Installing the VoIP Outdoor Intercom
Intercom Setup
Table 2-21.
CyberData Corporation
66
