A.8.2 Concrete Wall Mounting Option (Not Provided)
Figure A-14
Note: To mount the intercom, use methods
Operations Guide
illustrates a concrete wall mounting option for the VoIP Outdoor Intercom.
Figure A-14. Optional Concrete Wall Mounting
compliant with local electrical codes.
930796N
Hole Plug
Asse bl
(Hole Plug,
Washer & Nut)
1/4" Carriage
Screw
(Not Provided)
Network
Cable In
(Not Provided)
Mounting the Intercom
Additional Mounting Options
1/4" Concrete
Wall Anchors
(Not Provided)
Spacer
(One Provided)
1/2" Set Screw
Connector
(Not Provided)
1/2" Conduit
(Not Provided)
CyberData Corporation
98
