Rack-mount installation

3. If any items are damaged or missing, call the IBM Quality Hotline
toll-free at 1-800-442-6773 within the United States and Canada.
In other locations direct dial 770-858-8459.
CAUTION
The weight of this part or unit is more than 55 kg (121.2 lb.). It takes
specially-trained persons and/or a lifting device to safely lift this
part or unit.
(C011)
ATTENTION ! Safe installation of the director requires the use of a lift tool,
PN 09P2481, and a 24-inch load plate, PN 11P4369. See
page 19 for complete ordering information.
Perform the following steps to install the director in a customer-
supplied equipment rack. A #2 Phillips screwdriver is required.
1. Locate the rack-mount position as directed by the customer. The
director is 20 inches (12 U) high.
2. Verify all FRUs, including the SFP and XFP optical transceivers,
logic cards, fans, and power supplies are installed as ordered.
3. Open the rack-mount kit and inspect the contents. Refer to the
enclosed bill of materials and verify all parts are delivered.
4. Using installation instructions delivered with the rack-mount kit
and a #2 Phillips screwdriver, install the director in the equipment
cabinet.
5. Connect the U.S. AC power cords to the right (PS0) and left (PS1)
receptacles at the rear of the director
DANGER
An electrical outlet that is not correctly wired could place hazardous
voltage on metal parts of the system or the devices that attach to the
system. It is the responsibility of the customer to ensure that the
outlet is correctly wired and grounded to prevent an electrical shock.
(D004)
Ordering the lift tool
(Figure 15).
