Canon Laser Class 810 Basic Operation Manual page 295

4
Lift and hold the transcription
frame (A), then remove the
jammed paper (Only for 2-sided
copying).
5
Close the left cover.
Be careful not to get your fngers caught.
6
If you use the optional paper
cassette, open the cover on the left
side of the optional paper cassette.
Remove any jammed paper, then
close the cover.
7
Pull out the paper cassette and
push the corners of the stack
under the tabs.
11-5
