DIGITAL-LOGIC Microspace MSM586SEN Technical User Manual page 89

DIGITAL-LOGIC AG
Pin Normal Description
57 n/c
58 n/c
59 n/c
60 n/c
61 DU Don't use
62 DU Don't use
63 VCC +5 VDC
64 VCC +5 VDC
65 DU Don't use
66 DU Don't use
67 /WE Read/Write
68 n/c Not connected
69 /RAS0 Row Address Strobe 0
70 n/c Not connected
71 /RAS1 Row Address Strobe 1
72 n/c Not connected
Information taken from "The Hardware Book"
MSM586SEN/SEV Manual V1.5E
Pin Normal Description
129 VCC +5 VDC
130 VCC +5 VDC
131 DQ28 Data 28
132 DQ60 Data 60
133 DQ29 Data 29
134 DQ61 Data 61
135 DQ30 Data 30
136 DQ62 Data 62
137 DQ31 Data 31
138 DQ63 Data 63
139 VSS Ground
140 VSS Ground
141 SDA
142 SCL
143 VCC +5 VDC
144 VCC +5 VDC
89
