DIGITAL-LOGIC Microspace MSM586SEN Technical User Manual page 87

DIGITAL-LOGIC AG
Pin
Pin 28
Pin 29
Pin 30
Pin 31
Pin 32
Pin 33
Pin 34
Pin 35
Pin 36
Pin 37
Pin 38
Pin 39
Pin 40
Pin 41
Pin 42
Pin 43
Pin 44
Pin 45
Pin 46
Pin 47
Pin 48
Pin 49
Pin 50
Pin order Pin 25
(solder view)
Pin 50
Signal
= D12
= D13
= D14
= D15
= CS1 (active low)
= (Vs1) NC
= IOR (active low)
= IOW (active low)
= Vcc
= IRQ
= Vcc
= CEL
= (VS2) NC
= Reset (active low)
= IOCHRDY (active low)
= (INPACK-) NC
= Vcc
= LED (active low)
= PDIAG
= D8
= D9
= D10
= GND
Pin 1
Pin 26
87
MSM586SEN/SEV Manual V1.5E
