2 O
VERVIEW
2.1

Standard Features

The MICROSPACE PC/104 is a miniaturized modular device incorporating the major elements of a PC/AT
compatible computer.
It includes standard PC/AT compatible elements, such as:
- Powerful ELAN520 133MHz
- BIOS ROM
- SODIMM 16 to 128 MBytes 70ns (32bit device, no ECC supported)
- Timers
- DMA
- Real-time clock with CMOS-RAM and battery buffer
- LPT1 parallel port
- COM1, COM2, COM3, COM4 serial port
- Speaker interface
AT-keyboard interface or PS/2-keyboard interface
-
PS/2 mouse interface
-
- Floppy disk interface
- AT-IDE harddisk interface
- VGA/LCD video interface
- PC/104 embedded BUS
2.2

Unique Features

The MICROSPACE includes all standard PC/AT functions plus unique DIGITAL-LOGIC AG enhancements,
such as:
- Single 5 volt supply
LAN Ethernet 82559ER
-
DOC2000
-
Compact card. typ 1
-
- Watchdog
- Power-fail
EEPROM for setup and configuration
-
Core- and VGA BIOS downloadable
-
JTAG for debugging with CADUL KIT
-
(NO Power management functions yet)
-
UL approved parts
-
