29H DEBUG_RAM_SIZE_DONE
2AH DEBUG_RAM_PROT_EXIT
2BH DEBUG_CS_SHADOW_SETUP
2CH DEBUG_VIDEO_EQUIP_INIT_INIT
2DH DEBUG_VIDEO_BW_SEARCH
2EH DEBUG_VIDEO_COLOR_SEARCH
2FH DEBUG_VIDEO_SIGNON
30H DEBUG_OEM_CONFIG_KBD_CTL
31H DEBUG_KEYB_PRESENT_TEST
32H DEBUG_KEYB_TEST_IRQ1
33H DEBUG_KEYB_TEST_CMD
34H DEBUG_RAM_FULL_TEST
35H DEBUG_RAM_PROT_ENTRY_2
36H DEBUG_RAM_TEST_DONE
37H DEBUG_RAM_PROT_EXIT_2
38H DEBUG_KEYB_OUTPUT_PORT
39H DEBUG_CS_CACHE_SETUP
3AH DEBUG_HWIO_TEST_PERIODIC
3BH DEBUG_GEN_CHECK_RTC
3CH DEBUG_GEN_INIT_HARD_VECS
3DH DEBUG_MOUSE_INIT
3EH DEBUG_KEYB_SET_LEDS_1
3FH DEBUG_OEM_DEVICE_CONFIG
40H DEBUG_CS_CONFIG_PORTS
41H DEBUG_FLOP_INIT
42H DEBUG_WINI_INIT
43H DEBUG_HWIO_ROM_INIT
44H DEBUG_OEM_INIT_POWER_MAN
45H DEBUG_KEYB_SET_LEDS_2
46H DEBUG_HWIO_FIND_80X87
47H DEBUG_OEM_LAST_MINUTE_INIT
48H DEBUG_MISC_LAUNCH_INT19
49H DEBUG_BEGIN_BOOT_CODE
17.2.4

Error Beep codes

S-S-S-P-S-S-L-P
S-S-S-P-S-L-S-P
S-S-S-P-S-L-L-P
S-S-S-P-L-S-S-P
S-S-S-P-L-S-L-P
S-S-S-P-L-L-S-P
S-S-S-P-L-L-L-P
S-S-L-P-S-S-S-P
S-S-L-P-S-S-L-P
S=Short, L=Long, P=Pause
MSM586SEN/SEV Manual V1.5E
RAM test completed
Protected mode exit successful
Setup Shadow
Going To Initialize Video
Search For Monochrome Adapter
Search For Color Adapter
Signon messages displayed
special init of keyboard ctlr
Test If Keyboard Present
Test Keyboard Interrupt
Test Keyboard Command Byte
TEST, Blank and count all RAM
Protected mode entered safely (2).
RAM test complete
Protected mode exit successful
Update OUTPUT port
Setup Cache Controller
Test If 18.2Hz Periodic Working
test for RTC ticking
initialize the hardware vectors
Search and Init the Mouse
Update NUMLOCK status
special init of COMM and LPT ports
Configure the COMM and LPT ports
Initialize the floppies
Initialize the hard disk
Initialize option ROMs
OEM's init of power management
Update NUMLOCK status
Test For Coprocessor Installed
OEM functions before boot
Dispatch To Op. Sys. Boot
Jump Into Bootstrap Code
The DMA page registers are faulty.
The refresh circuitry is faulty.
The ROM checksum is incorrect.
The CMOS RAM test failed.
The DMA controller is faulty.
The interrupt controller failed.
The 8042 keyboard controller failed.
No video adapter was found.
No RAM is installed. No message is displayed.
