Optional:
The wiring of the parallel DOS/Link-Cable (DSUB 25pin) is as follows:
PC1 (Host)
Signal Name DSUB-Pin Number
D0
D1
D2
D3
D4
ERROR#
SLCT
PE
ACK#
BUSY
AFDT#
INIT#
SLCTIN#
STROBE#
GND
11.1.4

Restrictions

Keep the following restrictions in mind, when using the ESC or writing programs that should also work with
redirection:
WindowsNT denies direct access to hardware I/O ports. If you plan to use REMHOST in a WindowsNT
•
environment, an additional software package is required, that gives access to the specific I/O ports. This
software package can be achieved by FS FORTH-SYSTEME.
Avoid direct writes to video RAM. There is no mechanism to detect and transfer these outputs.
•
Since DOS7 of Windows95, standard console output is partially written to the video screen. So you will
•
see only some characters displayed on the host machine, while the rest is displayed on the target's
video display.
Avoid video calls that uses registers other than AX, BX, CX and DX. To speed up video output, only
•
these registers will be transferred. The other registers will be typically used as pointers to data buffers.
Formatting of remote floppy is not supported.
•
Don't rely on „Keyboard Intercept" INT15/4F. This function is no longer available.
•
KEYB.COM is no longer needed on the target machine. Instead, the current keyboard handler of your
•
host computer is automatically used.
Don't press Ctrl-Alt-Del, while redirection is active. This will not reboot your target system, but your
•
host machine !
12 S
OFTWARE
On the MICROSPACE Application CD you will find all tools and drivers you will need to work with the card.
If you are not sure about the topicality of the software, please visit our homepage at
http://www.digitallogic.com
2
3
4
5
6
15
13
12
10
11
14
16
17
1
25
to get the latest relases !
100
MSM586SEN/SEV Manual V1.5E
PC2 (Target)
DSUB-Pin Number
15
− −
13
− −
12
− −
10
− −
− − 1
− −
− −
− −
− −
− −
14
− −
16
− −
17
− −
− −
25
− −
Signal Name
ERROR#
SLCT
PE
ACK#
1 BUSY
2 D0
3 D1
4 D2
5 D3
6 D4
AFDT#
NIT#
SLCTIN#
1 STROBE#
GND
