DIGITAL-LOGIC Microspace MSM586SEN Technical User Manual page 315

DIGITAL-LOGIC AG
J7M VGA Monitor (CRT-Signals)
J7 L/M Header
40 Pin -L 10 Pin -M
Pin 32 Pin 2
Pin 34 Pin 4
Pin 36 Pin 6
Pin 38 Pin 8
Pin 39 Pin 9
Pin 31 Pin 1
Pin 33 Pin 3
Pin 35 Pin 5
Pin 37 Pin 7
Pin 40 Pin 10
The VGA-CRT signals from J7 must be wired to a standard VGA HiDensity DSub connector (female):
The LCD signals must be wired panel specific.
Solderside view of the female 15pin HiDSub
6
J55 DDC connector (not assembled)
Pin Signal
Pin 1 = VSDA
Pin 2 = VSCL
J43 10/100 BASE-T Interface connector
J43 Pin * Signal
Pin 1 = TX+
Pin 2 = TX-
Pin 3 = RX+
Pin 4 = RX-
* This signals are ready to connect directly to a RJ-45 connector.
15 pins HiDensity D-SUB
Signal Pin
VGA red Pin 1
VGA green Pin 2
VGA blue Pin 3
Horizontal synch Pin 13
Vertical synch Pin 14
Pin 5 + 11
Ground Pin 5, 6, 7, 8
LCD-P20
LCD-P21
LCD-P22
LCD-P23
1 2 3 4
Red Green Blue
7 8 9 10
GND
11 12 13 14
Hsyn VSyn
Pin
Pin
Pin
RJ-45 Pin
Pin 1
Pin 2
Pin 3
Pin 6
MSM586SEN/SEV Manual V1.5E
Signal
Red
Green
Blue
H- synch
V- synch
Bridge
Ground
5
GND
15
69000
V3
U4
Signal
= TX+
= TX-
= RX+
= RX-
83
1 2 3 4 5 6 7 8
RJ-45
