DIGITAL-LOGIC AG
J4
Serial Port COM1 (from ELAN520)
Header onboard:
RS232 Signal
Pin 1
= DCD
Pin 2
= DSR
Pin 3
= RxD
Pin 4
= RTS
Pin 5
= TxD
Pin 6
= CTS
Pin 7
= DTR
Pin 8
= RI
Pin 9
= GND
Pin10
= open
* RS422 is optional. If you want to use RS485 you have to make a short circuit between the header pins 2, 4 and 6.
J41
Serial port COM2 (from ELAN520)
Header onboard:
RS232 Signal
Pin 1
= DCD
Pin 2
= DSR
Pin 3
= RxD
Pin 4
= RTS
Pin 5
= TxD
Pin 6
= CTS
Pin 7
= DTR
Pin 8
= RI
Pin 9
= GND
Pin10
= open
* RS422 is optional. If you want to use RS422 you have to make a short circuit between the header pins 2, 4 and 6.
J50
Serial port COM 3 (from 37B787)
Header onboard:
RS232 Signal
Pin 1
= DCD
Pin 2
= DSR
Pin 3
= RxD
Pin 4
= RTS
Pin 5
= TxD
Pin 6
= CTS
Pin 7
= DTR
Pin 8
= RI
Pin 9
= GND
Pin10
= open
* RS422 is optional. If you want to use RS485 you have to make a short circuit between the header pins 2, 4 and 6.
J49
Serial port COM 4 (from 37B787)
Header onboard:
RS232 Signal
Pin 1
= DCD
Pin 2
= DSR
Pin 3
= RxD
Pin 4
= RTS
Pin 5
= TxD
Pin 6
= CTS
Pin 7
= DTR
Pin 8
= RI
Pin 9
= GND
Pin10
= open
* RS422 is optional. If you want to use RS485 you have to make a short circuit between the header pins 2,4 and 6
MSM586SEN/SEV Manual V1.5E
RS485 Signal *
B
A
GND
RS485 Signal *
B
A
GND
RS485 Signal *
B
A
GND
RS485 Signal *
B
A
GND
78
D-SUB connector:
Pin 1
Pin 6
Pin 2
Pin 7
Pin 3
Pin 8
Pin 4
Pin 9
Pin 5
D-SUB connector:
Pin 1
Pin 6
Pin 2
Pin 7
Pin 3
Pin 8
Pin 4
Pin 9
Pin 5
D-SUB connector:
Pin 1
Pin 6
Pin 2
Pin 7
Pin 3
Pin 8
Pin 4
Pin 9
Pin 5
D-SUB connector:
Pin 1
Pin 6
Pin 2
Pin 7
Pin 3
Pin 8
Pin 4
Pin 9
Pin 5
