The COM 1/2/3/4 serial interface cable

DT terminal for dual row 0.1" (2.54 mm grid) and 1.27 mm flat cable.
COM1/2
ATTENTION:
- Do not short-circuit these signal lines.
- Never connect any pins either on the same plug or to any other plug on the MICROSPACE
MSM586SEV. The +/-10 volts will destroy the MICROSPACE core logic immediately. No warranty in
this case!
- Do not overload the output: max. output current converters: 10 mA
Line of pin 1
1 2
9 10
95
MSM586SEN/SEV Manual V1.5E
1
6
2
COM1
7
9pin D-Sub
3
8 male
4
9
5
