Eeprom Saved Cmos Setup - DIGITAL-LOGIC Microspace MSM586SEN Technical User Manual

DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
5.5

EEPROM saved CMOS Setup

The EEPROM has different functions, as listed below:
• Backup of the CMOS-Setup values.
• Storing system informations like: version, production date, customisation of the board, CPU type.
• Storing user/application values.
The EEPROM will be updated NOT automatically after exiting the BIOS setup menu. The system will operate
also without any CMOS battery. While booting up, the CMOS is automatically updated with the EEPROM
values.
To store your defined configuration to the EEPROM, you have to apply "save to EEPROM" in the menu
"exit".
To get the real default values (factrory settings), please use the tool "DEFAULT.EXE" which is located on the
product CD or the download area in the support center.
• The user may access the EEPROM through the INT15 special functions.
• The system information are read only information. To read, use the SFI functions.
46
