Memory 69000 Mono STN-DD panels

Hor. Vert. Color
Resol. Resol. bpp
640 480 8
640 480 8
640 480 8
640 480 8
640 480 16
640 480 16
640 480 16
640 480 16
640 480 24
640 480 24
640 480 24
640 480 24
800 600 8
800 600 8
800 600 8
800 600 8
800 600 16
800 600 16
800 600 16
800 600 16
800 600 24
800 600 24
800 600 24
800 600 24
! Means not possible resolution with the 4Mb Video RAM
Refr. DCLK MEM
Hz Mhz kByte
60 25.175 300
72 31.500 300
75 31.500 300
85 36.000 300
60 25.175 600
72 31.500 600
75 31.500 600
85 36.000 600
60 25.175 900
72 31.500 900
75 31.500 900
85 36.000 900
60 40.000 469
72 50.000 469
75 49.500 469
85 56.250 469
60 40.000 938
72 50.000 938
75 49.500 938
85 56.250 938
60 40.000 1406
72 50.000 1406
75 49.500 1406
85 56.250 1406
MSM586SEN/SEV Manual V1.5E
Cursor FB/C FB/M
kByte kByte kByte
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 38
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
4.2 0 59
76
Video Total Total
Input with w/o
kByte Video Video
300 642 342
300 642 342
300 642 342
300 642 342
300 942 642
300 942 642
300 942 642
300 942 642
300 1242 942
300 1242 942
300 1242 942
300 1242 942
300 832 532
300 832 532
300 832 532
300 832 532
300 1300 1000
300 1300 1000
300 1300 1000
300 1300 1000
300 1769 1469
300 1769 1469
300 1769 1469
300 1769 1469
