6.4

VGA/LCD BIOS support

Each LCD display needs a specific adapted VGA-BIOS.
This product is equipped with the CRT standard VGABIOS.
To connect a LCD display to this product, you need to perform the following:
1. Check the FP_LIST.PDF if the LCD BIOS is available.
Get the latest VGA-BIOS at our webpage
IF THE LCD BIOS IS AVAILABLE:
2. In the FLATPANEL-SUPPORT documentation the connection between the LCD
and this product will be described.
3. DOWNLOAD the corresponding LCD-BIOS with the utility DOWN_000.EXE
Go the the section 4.8.2 DOWNLOAD THE VGABIOS in this manual and follow those steps.
4. Restart the system and check the VGA-BIOS header message. The LCD name must be
visible for only a short time. The VGABIOS message appears as first info page on the screen.
5. Stop the system, connect the LCD to the system and restart again
6. If on the LCD no image appears, as soon as the monitor begins to show the first text, stop the
system immediately, otherways the LCD will become damaged.
7. Check the LCD connection again.
FOR A NEW LCD TYPE, NOT AVAILABLE NOW:
If the LCD BIOS for your LCD is not available, DIGITAL-LOGIC will adapt the LCD and provide you with one
working cable. To initialise this, we need the following points from you:
1. An order to adapt the LCD (for the costs ask your sales contact)
2. Send the LCD panel, a datasheet, a connector to the LCD and the inverter for the backlight
ATTENTION:
DIGITAL-LOGIC AG is never responsible for a damaged LCD display. Even when there are mistakes in the
BIOS or in any documentation for the LCD.
