6 VGA, LCD

6.1

VGA / LCD controller 69000

69000 High Performance Flat Panel / CRT HiQVideo
• Highly integrated Flat Panel and CRT GUI Accelerator & Multimedia Engine, Palette/DAC, Clock Synthe-
sizer, and integrated frame buffer
• Integrated High performance SDRAM memory. 2MB integrated memory, 83 MHz SDRAM operation
TM
• HiQColor Technology implemented with TMED (Temporal Modulated Energy Distribution)
• Hardware Windows Acceleration
• Integrated composite NTSC / PAL Support
• Hardware Multimedia Support
• High-Performance Flat Panel Display resolution and color depth at 3.3V
• 36-bit direct interface to color and monochrom, single drive (SS), and dual drive (DD), STN & TFT panels
• Advanced Power Management features minimize power usage in:
- Normal operation
- Standby (Sleep) modes
- Panel-Off Power-Saving Mode
• VESA Standards supported
• Fully Compatible with IBM
• Driver Support for Windows 3.1, Windows 95/98, Windows NT3.1/NT4.0
6.2

VGA / LCD BIOS for 69000

VGA BIOS
The 69000 VGA BIOS is an enhanced, high performance BIOS that is used with the 69000 VGA Flat
Panel/CRT Controller to provide an integrated Flat panel VGA solution. The BIOS is optimized for 69000
VGA Flat Panel/CRT Controller and provides:
Full compatibility with the IBM VGA BIOS
Support for monochrome LCD, 640x480, 800x600, 1024x768 and 1280x1024 TFT or STN displays.
Optional support for other displays.
Supports VESA BIOS Extensions, including VBE 2.0, VBE/DDC 1.0, and VBE/PM 1.0.
Supports either VESA local bus or PCI bus
Extended BIOS functions which offer easy access to 69000 control ler features and capabilities
Support for simultaneous display
44K BIOS supports 8 panels
48K BIOS supports 16 panels
®
VGA
71
MSM586SEN/SEV Manual V1.5E
TM
Accelerator with Integrated Memory
