X3 LAN LED
Pin Signal
1 LILEDX / Link LED
2 VCC3
3 ACTLEDX / Activity LED
X2 JTAG connector (debugging)
Pin Signal
1 GND
3 TCK
5 TMS
7 TDI
9 TDO
11 TRST
X1 Spare connector (not assembled), for test purposes only
Pin Signal
1 PD0
3 PD2
5 PD4
7 PD6
9 PD8
11 PD10
13 PD12
15 PD14
17 PA0
19 PA2
21 PBREQ
23 PBGNT
25 TCLK
27 WSTR
29 CLKTEST
J60 Ext. HDD Led, (new since V2.2)
Pin Signal
1 Vcc
Remarks
330 Ohm resistor on board
330 Ohm resistor on board
Pin Signal
2 VCC
4 CMDACK
6 BREAK
8 STOP
10 TRACE
12 RESETIN
Pin Signal
2 PD1
4 PD3
6 PD5
8 PD7
10 PD9
12 PD11
14 PD13
16 PD15
18 PA1
20 ICEDISABLE
22 TV
24 PRW
26 WENABLE
28 WDENA
30 GND
Pin Signal
2 HDD
