Speaker interface

One of the board's CPU device provides the logic for a PC compatible speaker port. The speaker logic signal
is buffered by a transistor amplifier, and provides approximately 0.1 watt of audio power to an external 8 ohm
speaker. Connect the speaker between VCC and speaker output to have no quiescent current.
4.3.6

LAN Interface:

Product Features
Data Rates (Mb/s)
I/O Interface
Bus Frequency
Package (dimensions)
Pin Count
TCP, UDP, IPv4 Checksum Offload
Wired for Management support
PXE support
Alert on LAN 2
ASF (Tx and Rx alerting)
SMBus interface
Wake on LAN
Magic Packet
Remote power up support
32-bit PCI/CardBus interface
Modem Interface
VLAN support
Device ID
Available in Ext. Temp (-25-85C)
Software/Driver Support
ANS support (link aggregation, failover)
NDIS 3, 4
NDIS 5 (Win2K, WinXP)
WinXP Embedded
WinNT Embedded
WinCE 2.12
WinCE 3.0
WinCE 4.0
Linux
Solaris
Netware
SCO OpenServer
FreeBSD
NetBSD
VxWorks
BSD/OS
pSOS
QNX
*through 3rd party ISV
82559 82559ER
10/100 10/100
32-bit PCI 32-bit PCI
33Mhz 33Mhz
15x15mm 15x15mm
196 pin TBGA 196 pin TBGA 196 pin TBGA 196 pin TBGA
Yes -
Yes -
Yes 3rd party only
Yes -
- -
Yes -
Yes -
Yes -
Yes -
Yes -
Yes -
Yes -
1229 1209
- Yes
82559 82559ER
Yes -
Yes Yes
Yes -
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes -
Yes -
Yes -
Yes -
Yes* Yes*
Yes* Yes*
Yes* Yes*
- -
Yes* Yes*
Yes* Yes*
34
MSM586SEN/SEV Manual V1.5E
82551 82551ER
10/100 10/100
32-bit PCI 32-bit PCI
33Mhz 33Mhz
15x15mm 15x15mm
Yes Yes
Yes -
Yes 3rd party only
- -
Yes -
Yes -
Yes -
Yes -
Yes -
Yes -
Yes -
Yes -
1229 1209
- TBD
82551 82551ER
Yes -
Yes Yes
Yes -
Yes Yes
Yes Yes
Yes -
Yes Yes
Yes Yes
Yes Yes
Yes -
Yes -
Yes -
Yes* TBD*
Yes* TBD*
Yes* Yes*
TBD* TBD*
- -
TBD* TBD*
82540EM
10/100/1000
32-bit PCI
66Mhz
15x15mm
196 pin BGA
Yes
Yes
Yes
-
Yes
Yes
Yes
Yes
Yes
-
-
Yes
100E
-
82540EM
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes*
Yes*
Yes*
TBD*
-
TBD*
