DIGITAL-LOGIC Microspace MSM586SEN Technical User Manual page 14

DIGITAL-LOGIC AG
External Interface
Videointerfaces
USB V1.1
LPT1:
COM1:
COM2:
COM3:
COM4:
Keyboard:
Mouse:
Floppy:
Harddisk:
Speaker:
Powersupply:
Input:
Protection:
Spec.
Power Consumption
At 5V
Standby
Poweroff
Physical Characteristics
Dimensions:
Weight:
Operating Environment
Relative Humidity:
Vibration operating:
Vibration nonoperating: IEC68-2-6 10-50Hz, 0.15mm and 55-500Hz,
Shock operating:
Shock nonoperating:
Altitude
Temperature operating
Extended Temp. option MIL-810-501/502
Temperature storage
*) The backupbattery is limited on –40° C to +85° C operating and storage temperature !
Specification
CRT1, LCD for TFT and STN
Not available
Internal
RS232
RS232
RS232
RS232
PS/2
PS/2
26pin FCC Interface for TEAC Minifloppy
1 channel 44pin RM2.0mm ATAIDE-cable
0.1Watt Speaker
Nom. 5V Tolerance +/- 3%
Not integrated, EMI filtered must be added external
Specification
Typical 1.5 Amp.
Not available
0mA
Specification
PC/104
Length: 91mm
Depth: 96mm
Height: 25mm
170gr
Specification
5 - 90% non condensing
IEC68-2-30 at -20° to +50° C operating
IEC68-2-6 10-50Hz, 0.075mm and 55-500Hz, 1.0G
IEC68-2-27 10G, 11ms ½ sine
IEC68-2-27 50G, 11ms, ½ sine
IEC68-2-13 4571meter operating
IEC68-2-1,2,14: Standard
Extended temperatur -40° C to +85° C
IEC68-2-1,2,14: -65° C to +125° C *)
MSM586SEN/SEV Manual V1.5E
-20°C to +60° C
14
2.0G
