J7L LCD connector
VGA-LCD Interface (flatpanel signals):
Signals P20-P23 are located on the J7M connector
Pin Signal
1 M / DE Signal
3 P18
5 VCC-LCD (1A),
Selected by J51
7 VEESAVE (5V/1A)
9 VBACKSAVE (12V/1A)
11 P2
13 P1
15 P0
17 Contrast resistor pin 1 *)
19 Contrast resistor pin 2 *)
21 P4
23 P8
25 P10
27 P12
29 P14
Rem:
Pin 9 (+12V) will be supplied from J48 (pin 4) or J40 (pin B9).
-
*)
Contrast electronics is not assembled
Contrast is reserved to be controlled via INT15 in later bios versions.
-
Pin Signal
2 FLM
4 Line Pulse LP
6 GND
8 Shift Clock
10 P3
12 P17
14 P16
16 P7
18 P6
20 P5
22 P19
24 P9
26 P11
28 P13
30 P15
