DIGITAL-LOGIC Microspace MSM586SEN Technical User Manual page 257

DIGITAL-LOGIC AG
12V +/- 5%
used only for the flatpanel supply.
GROUND = 0V
used for the entire system.
VCC, +5V +/- 0.25V
for logic and harddisk/floppy supply.
For further Informations about PC/104 and PC/104plus, please refer to the PC/104 specification
manual which is available on the internet.
MSM586SEN/SEV Manual V1.5E
