DIGITAL-LOGIC AG
MSM586SEN/SEV Manual V1.5E
8.1
Jumpers locations on the MSM586SEN/SEV
V2.2/2.3/2.3a/2.4/2.5
Top side:
Remark:
The connectors J49/50 of the old Version V2.1. were not at the same position, as above defined. There were closer placed.
91
