DIGITAL-LOGIC AG
13.2

Intel 82559 Ethernet chip

Create a directory C:\LAN100 on your harddisk.
-
Copy the programs and drivers of x:\DRIVERS\NETWORK\INTEL\82559\ onto your HD.
-
13.2.1

Installation example for MSDOS Novell 4.11

run "setup.exe" in the directory c:\lan100\...
-
choose "install network drivers"
-
choose "Novell"
-
choose "DOS odi client"
-
choose "continue installation"
-
the settings in this menu are optional (preferred server (optional); frame type = 802.2)
-
press F10
-
select a name for the directory of you choice, for example: "c:\network"
-
press enter
-
choose "modify autoexec.bat"
-
exit setup
-
Change the file "startpro.bat" of c:\network in:
c:
cd \network
lsl
e100bodi
ipx.odi
cd dos
vlm
cd \
Copy the directory x:\drivers\network\intel\client\dos from our product CD into the directory c:\network\
13.2.2

Driver installation WINDOWS 95

Copy Intel Pro100+ drivers on HDD (x:\drivers\network\intel\82559).
-
De-install all network drivers under Windows95 in system and software folders and restart Windows.
-
Networkcard Pro10 PCI will be auto-detected and all drivers can be installed (of the copied directory).
Restart Windows and there is a failure message.
-
Call up the networkcard-preferences in the devicemanager and update the drivers.
-
Choose the Intel 8255x-based PCI Ethernet Adapter (10/100) out of the list.
-
Shut down Windows and switch off the power supply unit.
-
Boot up again and the network is installed.
-
13.2.3

Driver installation WINDOWS 98SE

Update the driver from the Intel® PRO/10+PCI device in the device manager.
-
Choose the option "select list with drivers".
-
Choose the "Intel 8255xx based Ethernet PCI Adapter(10/100)" .
-
Go on. If you get a failure report, press ok.
-
If the PC hangs, switch off/on the power.
-
After reboot, you must activate the Intel 8255xx driver in the device manager.
-
MSM586SEN/SEV Manual V1.5E
103
