ESCRIPTION OF THE CONNECTORS
Flat cable
44pin IDE is: IDT Terminal for Dual Row (2.00mm grid) and 1.00mm flat cable
•
All others are: IDT Terminal for Dual Row 0.1" (2.54mm grid) and 1.27mm flat cable
•
Connector
J02 FDD micro
J04 COM1 internal ELAN
J07 LCD / VGA connector
J22 HDD primary
J27 Utility; PS/2- mouse- keyboard; reset;
speaker
J40 PC104 bus
J41 COM2 internal ELAN
J43 LAN
J48 Power supply / IrDA
J49 COM D SUPER I/O
J50 COM C SUPER I/O
J55 DDC (not assembled)
J60 Ext. HDD Led
B1 Battery Lithium 3.6V
P1 LPT
U95 SODIMM socket
U96 Compact card holder, typ1
U112 DOC2000 IC socket
X2 JTAG connector
X1 ELAN520 spare (not assembled)
X3 LAN LED connector
Texture
77
MSM586SEN/SEV Manual V1.5E
Pin Remarks
26 FCC micro
2x5
2x20
2x22
2x5
104
2x5
4
8
(2x10)
(2x10)
2
2
2
2x13
144
50
2x16
2x6
2x15
3
2.54mm
2.54mm
2mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2.54mm
2mm
2mm
2.54mm
