I/O Ad- Read/Write
dress Status
0021h R / W
0021h W
0020h R
0021h W
Continued...
Description
PIC master interrupt mask register (OCW1)
bit 7 = 0 Enable parallel printer interrupt
bit 6 = 0 Enable diskette interrupt
bit 5 = 0 Enable hard disk interrupt
bit 4 = 0 Enable serial port 1 interrupt
bit 3 = 0 Enable serial port 2 interrupt
bit 2 = 0 Enable video interrupt
bit 1 = 0 Enable kybd/pointing device/RTC inter-
rupt
bit 0 = 0 Enable interrupt timer
PIC OWC2 (if bits 4-3 = 0)
bit 7 = Reserved
bits 6-5 = 000 Rotate in automatic EOI mode (clear)
001 Nonspecific EOI
010 No operation
011 Specific EOI
100 Rotate in automatic EOI mode (set)
101 Rotate on nonspecific EOI command
110 Set priority command
111 Rotate on specific EOI command
bits 4-3 = Reserved (should be 00)
bits 2-0 = Interrupt request to which the command
applies
PIC interrupt request and in-service registers programmed
by OCW3
Interrupt request register
bits 7-0 = 0 No active request for the corresponding
1 Active request for the corresponding
Interrupt in-service register
bits 7-0 = 0 Corresponding interrupt line not cur-
rently
1 Corresponding interrupt line is currently
being serviced
PIC OCW3 (if bit 4 = 0, bit 3 = 1)
bit 7 = Reserved (should 0)
bits 6-5 = 00 No operation
01 No operation
10 Reset special mask
11 Set special mask
bit 4 = Reserved (should be 0)
bit = Reserved (should be 1)
bit 2 = 0 No poll command
1 Poll command
bits 1-0 = 00 No operation
01 Operation
10 Read interrupt request register on next
11 Read interrupt in-service register on
0020h
52
MSM586SEN/SEV Manual V1.5E
interrupt line
interrupt line
being serviced
read at port 0020 h
next read at port
