  • Page 1 Océ User manual Arizona 250 GT Arizona 250 GT User Guide...
  • Page 2 Océ-Technologies B.V. Copyright © 2007, Océ-Technologies B.V. Venlo, The Netherlands. All rights reserved. No part of this work may be reproduced, copied, adapted, or transmitted in any form or by any means without written permission from Océ Display Graphics Systems. Océ-Technologies B.V.

  • Page 3: Table Of Contents

    Interlock Safety System ........24 Arizona 250 GT Safety Labels ....... . . 26 Safety Awareness .
  • Page 4 Arizona 250 GT Ink ........

  • Page 5: Introduction

    Chapter 1 Introduction...

  • Page 6: Preface

    Océ DGS on the Internet For further information on documentation and support for your Arizona 250 GT or for information on other Océ Display Graphics Systems products, please visit our web site: http://www.dgs.oce.com To provide feedback and report errors in this document: DGSTechnical.Writer@oce.com...
  • Page 7 Preface Responsibilities of the Operator The operator of the Arizona 250 GT must be properly trained. Océ provides training for the operator in the use of hardware and software at the time of installation. It is the customer's responsibility to ensure that only properly trained personnel operate the printer.

  • Page 8: Product Compliance

    Product Compliance Product Compliance Introduction This section details the compliance and agency standards that the Arizona 250 GT conforms to. It also provides manufacturing and contact information. Electromagnetic Compatibility This equipment generates, uses and radiates radio frequency energy and if not installed and used as designed or intended, may cause interference to radio communications.
  • Page 9 76.8dB). For all locations, provide noise protection enclosure or remove pump from location. Manufacturer: Océ Display Graphics Systems (ODGS) 13231 Delf Place - Building #501 Richmond, British Columbia Canada V6V 2C3 http://www.dgs.oce.com/ Direct Dial (604) 232-2345 - Fax (604) 273-2775...
  • Page 10 Product Compliance Representatives Marketing the Arizona 250 GT in Europe: Océ Technologies B.V. St. Urbanusweg 43, Venlo, The Netherlands P.O. Box 101, 5900 MA Venlo Telephone: (31) 77 359 2222 Fax: (31) 77 354 4700 E-mail: info@oce.com Océ-Deutschland GmbH Solinger Straße 5-7 45481 Mülheim/Ruhr...

  • Page 11: Chapter 2 Product Overview

    Chapter 2 Product Overview...

  • Page 12: Arizona 250 Gt Product Features

    Arizona 250 GT Product Features Introduction The Arizona 250 GT is a 4 color (CMYK) UV flatbed inkjet printer capable of producing large format images on various rigid and flexible media. The printer consists of a large vacuum table and moving gantry. The material is held flat and stationary on the vacuum table during printing.
  • Page 13 Arizona 250 GT Product Features Arizona 250 GT Specifications [1] Specifications (1 – 2) Feature Specification ™ Printing Technology Piezoelectric inkjet using Océ VariaDot imaging tech- nology; with two variable dot print heads per color, 8 in total. Print Speed...
  • Page 14 Océ VariaDot Variable Droplet Imaging Technology The Océ Arizona 250 GT offers superior print quality and ink economy through the use of Océ VariaDot imaging technology, the next evolution in piezoelectric inkjet technology that enables a print head to produce droplets of varying volume. This differs from the current piezoelectric print head technology that is restricted to the use of fixed droplets.
  • Page 15 Arizona 250 GT Product Features ™ Océ VariaDot for Reduced Ink Consumption A significant benefit of Océ VariaDot imaging technology is that it allows the use of only four inks (CMYK) for all areas of the printed image. This is very significant to the user in terms of ink consumption per square meter because the current "de facto...
  • Page 16 Arizona 250 GT Product Features Chapter 2 Product Overview...

  • Page 17: Chapter 3 Safety Information

    Chapter 3 Safety Information...

  • Page 18: Safety Guidelines For Ink Materials

    This section outlines the safety concerns involved with the handling and use of the UV ink and Flush for the Arizona 250 GT printer. Read all of the material in this section and also review the Material Safety Data Sheet (MSDS) documents before handling any UV ink or using the printer.
  • Page 19 Safety Guidelines for Ink Materials Handling UV Inks Read and practice safety guidelines as outlined in the MSDS for each ink. Post these documents in the work area as required by prevailing law. MSDS for all four inks are provided when you purchase inks. The following is a summary of the important safety aspects of the MSDS that are common to all UV inks.
  • Page 20 Safety Guidelines for Ink Materials [4] First-aid Measures Exposure Remedy Inhalation Remove to fresh air. If breathing is difficult, have a trained individual administer oxygen. If not breathing, give artificial respiration and have a trained individual administer oxygen. Get medical attention immediately.
  • Page 21 Safety Guidelines for Ink Materials [7] Exposure Controls Engineer- Local exhaust ventilation or other engineering controls are normally required when handling or using this product to avoid overexposure. Measures It is recommended that facilities storing or using this material be equipped with an eyewash and safety shower.

  • Page 22: Uv Curing System Safety

    The UV Curing System on the Arizona 250 GT generates hazardous levels of thermal, electrical and UV energies. The Arizona 250 GT printer uses UV-curable ink that needs a high energy level of UV light to cure. The system is made up of two medium pressure mercury arc lamps attached to the carriage.
  • Page 23 UltraViolet and Blue Light Hazards Categories Warning for Seated Individuals: The UV Emissions and Blue Light Emissions profile of the Arizona 250 GT is at it's worst for individuals in a seated position (Table Height of 90cm). Remove all chairs within 5 metres of the printer.

  • Page 24: Interlock Safety System

    Safety Monitoring Relay input circuits. This causes the system to isolate the power to the motion control motors, and also turns off the Arizona 250 GT curing system (UV lamps). The Maintenance Station and the Safety Gate on the carriage also have an interlock function.
  • Page 25 Interlock Safety System Safety Guard Interlock Function: The Safety Guard is an aluminum fence around the perimeter of the carriage. Motion Motors disabled when it is not properly seated include the Gantry Drive and Carriage Drive. Also UV Lamps switch Off (Not UV Cooling Fans), and Z-Axis drive initializes (Carriage drives to Top Position and Holds there).

  • Page 26: Arizona 250 Gt Safety Labels

    Arizona 250 GT Safety Labels Arizona 250 GT Safety Labels Introduction The safety labels are placed at strategic locations on the printer to warn the operator of possible dangers and hazards. It is important to be aware of the meaning of these labels to ensure safe operation of the printer.
  • Page 27 Arizona 250 GT Safety Labels [10] Safety Labels (2 – 3) Description Label Machine lockout: a reminder to turn off and lock out the AC power switch before servicing any electrical components. Located on the mains power switch. Warning: Electric Shock...
  • Page 28 Arizona 250 GT Safety Labels [10] Safety Labels (3 – 3) Description Label Crush Hazard: Keep hands clear while operating. A reminder that vertical move- ment of the carriage can be a crush hazard if hands or objects are placed in these locations.

  • Page 29: Safety Awareness

    This section contains two sets of principles that must be followed to assure maximum safety when operating the Arizona 250 GT printer. The first set uses negative examples to show you residual risks to avoid in order to prevent injury to the operator.
  • Page 30 Safety Awareness Situations and Actions to Avoid [11] [11] How NOT to use the Arizona 250 GT (1 – 3) Avoid these Situations For Your Personal Safety [11] Do not place your hand in the carriage pathway when print- er power is on. Do...
  • Page 31 Safety Awareness [11] How NOT to use the Arizona 250 GT (2 – 3) Avoid these Situations For Your Personal Safety [13] Do not push or force the gantry to move manually. Use the “Move Gantry” com- mand in the interface...
  • Page 32 [16] UV Lamp Hazard Residual Safety Risks The Arizona 250 GT is engineered to minimize machine components and operating procedures that may compromise operator safety. However, in order to maintain some machine operations and functionality, certain compromises are required. The following table documents some of these residual hazards.
  • Page 33 Caution: there may be a time lag between when a print job is issued and when the gantry movement actually begins as the UV lamps must warm up first. [12] [12] Arizona 250 GT Residual Risks (1 – 6) Risk Area...
  • Page 34 Safety Awareness [12] Arizona 250 GT Residual Risks (2 – 6) Risk Area Crushing/Shear Hazard [19] A high risk crush- ing/pinch hazard is created by the table and the carriage. [19] Table/Carriage Pinch Hazard [20] A high risk crush- ing/pinch hazard is...
  • Page 35 Safety Awareness [12] Arizona 250 GT Residual Risks (3 – 6) Risk Area Crushing/Shear Hazard [21] A medium risk crush- ing/pinch hazard is created by the gantry and the table frame. [21] Gantry/Table Pinch harard [22] A medium risk crush-...
  • Page 36 Safety Awareness [12] Arizona 250 GT Residual Risks (4 – 6) Risk Area Crushing/Shear Hazard [23] Shearing hazard A high risk shearing hazard is created by the carriage and the gantry frame from the bottom. [23] Carriage/Gantry Frame Shear Hazard...
  • Page 37 Safety Awareness [12] Arizona 250 GT Residual Risks (5 – 6) Risk Area Crushing/Shear Hazard [25] A high risk shearing hazard is created by the carriage and the gantry frame. [25] Hazard [26] Entanglement hazard A medium risk of fin-...
  • Page 38 Safety Awareness [12] Arizona 250 GT Residual Risks (6 – 6) Risk Area Crushing/Shear Hazard [27] A medium risk im- pact hazard is created by the carriage when cycling from left to right. [27] Carriage Impact Hazard [28] Heat hazard: the UV...

  • Page 39: How To Navigate The User Interface

    Chapter 4 How to Navigate the User Interface...

  • Page 40: Operator Interface Hardware

    Operator Interface Hardware Operator Interface Hardware Introduction The Operator interacts with the printer components to operate, maintain, and monitor the state of the printer: This section identifies and explains the functions of these components. [29] [29] User Interface Hardware [13] (1) Main Power Switch (9) Maintenance Station (2) Operator Control Station...
  • Page 41 Operator Interface Hardware Illustration [30] [30] Vacuum System Hardware [31] [31] Carriage Area Hardware...
  • Page 42 Component Function 1) Main Power The Arizona 250 GT has an AC power switch that turns the print- Switch er On and Off. The switch also serves as a lock-out device. It also has an AC power connector. All of these power-related items are located on the end of the electronics enclosure.
  • Page 43 Operator Interface Hardware [14] Hardware Interface Components (2 – 2) Component Function 9) Maintenance Daily printhead maintenance consists of an ink purge and suction Station cleaning of the printheads. The maintenance station cover is slid open to access the printheads and the suction nozzle. The main- tenance station is located under the carriage.
  • Page 44 Operator Interface Hardware Status of Beacon Lights States The status light indicate the following printer status to the operator. [15] [15] Status Lights Beacon Status Light Definition Possible Conditions Green Off Printer interlock system or Maintenance station panel the emergency stop switches has been opened or one the have been triggered.

  • Page 45: Graphical User Interface Display

    Graphical User Interface Display Introduction The Arizona 250 GT Graphical User Interface (UI) is displayed on the LCD flat panel monitor that is part of the Operator Control Station. The interface has four main working modules that are accessed by tabs located at the bottom of the display.

  • Page 46: Print Job Control Module

    Print Job Control Module Print Job Control Module Introduction Print Job Control is the default module displayed when the printer is switched on. From this module you can manage all aspects of working with print jobs and also control many features of the printer. The table "Job Control Panels" documents the number callouts and the rest of this section explains each area in more detail.
  • Page 47 Print Job Control Module Components of the Print Job Control Module [17] [17] Job Control Panels Component Function 1) Job Status Panel Displays the status and progress of print jobs 2) Printer Status Displays the last four lines of the log file - double-click to see Panel more of the log.
  • Page 48 Print Job Control Module 2) Printer Status Panel The printer status panel is in the top right corner of the display. It shows the last four lines of the printer log that contains printer status information and error messages. To see more of the log file, double-click on the panel. To the right of the status panel are two buttons: Pause/Resume print button.
  • Page 49 Print Job Control Module Lamp Power Allows the operator to control the power output of both UV Control lamps. To extend lamp life, use the lowest setting that provides adequate curing for a particular media. Lamp control appears only when Manual mode is selected from Image Quality Settings in the Printer Settings module.
  • Page 50 Print Job Control Module 4) Active Print Job List The active job list consists of a table, job count summary on top and job order control buttons on the left. A job count summary displays total number of active jobs and number of jobs put on hold.
  • Page 51 Print Job Control Module 7) Job information and parameters panel The job information area displays job parameters of the current print job. Some of the parameters may be modified. [19] Offsets A job's vertical and horizontal offset parameters can be changed with the mouse wheel when mouse cursor is posi- tioned over the field.

  • Page 52: Printer Settings Module

    Printer Settings Module Printer Settings Module Introduction The Printer Settings Module allows the operator to look at the network connection settings, configure how units are displayed, set the language preference, set the date and time, and set image quality settings. Illustration [35] [35] Printer Setup...
  • Page 53 Printer Settings Module Network Connection Settings Note: These settings do not usually need to be changed. They are available to troubleshoot possible network connection problems. One situation that would require changes is if your network does not use DHCP to automatically obtain network settings.
  • Page 54 Printer Settings Module Image Quality Settings Lamp Power Control Enables custom lamp power settings: Automatic Manual Note: If Manual is selected, a control panel for both UV lamps appears in the Command Bar on the Job Control Display Job Date / Time Allows you to select what is displayed with each print job - When the job was submitted or when the job was last printed.

  • Page 55: Special Prints Module

    Special Prints Module Special Prints Module Introduction The Special Prints module consist of two lists. The list on the left displays available special test prints. Most of these prints are used by service technicians to adjust and troubleshoot the printer. One exception that is of interest to the Operator is the the Nozzle Check (see ‘Print a Nozzle Check’...
  • Page 56 Special Prints Module How to Print a Special Print Go to the Print Job Control module to actually print the test print. It will appear in the active job list and is printed like any other print job. Note: Refer to the sections that document the two special prints for details on printing.

  • Page 57: Printer Upgrade Module

    As we are committed to improve and refine the quality and functionality of the Arizona 250 GT printer, there will be periodic upgrades to the underlying firmware and User Interface software. When an upgrade is released, all necessary software and firmware are bundled into a single package.
  • Page 58 Printer Upgrade Module How to Upgrade the Firmware and Software [20] Procedure Result 1) Click the Upgrade The Upgrade and Installation screen is displayed. tab. 2) Click the Share The 'Installation share status:' will change to 'Open'. This button on the toolbar. means that the printer's upgrade folder is now shared and available to access from the network.

  • Page 59: How To Operate The Arizona 250 Gt

    Chapter 5 How to Operate the Arizona 250 GT...

  • Page 60: Training Requirements

    Océ trains the operator in the use of the printer hardware and software at ® installation. However, this is not a substitute for formal ProductionHouse training. Operators of the Arizona 250 GT should be fully versed in the operation of Onyx ® ProductionHouse . For any operator unfamiliar with its operation, Onyx ®...

  • Page 61: How To Switch The Printer On And Off

    Position the power cord so that it does not pose a hazard when walking around or moving media or other objects near the printer. The Arizona 250 GT has an AC power switch that turns the printer On or Off. The switch also functions as an AC power lock-out switch.
  • Page 62 Attention: After powering the printer On, leave it running continuously, even when at idle. Failure to leave the printer powered on may result in ink draining out of the ink reservoirs. Chapter 5 How to Operate the Arizona 250 GT...
  • Page 63 How to Switch the Printer On and Off How to Power Off Turn the AC power switch to the OFF position. Close the ink valves on top of the Carriage ink reservoir to prevent the ink from draining out and filling the waste tray. [39] [39] Ink Shutoff Valves (Magenta, Yellow are Off - Black, Cyan still ON) Open the ink valves again when the power is turned back on.
  • Page 64 For additional safety, also disconnect the blue power plug. When the printer is successfully moved or the repair work is complete, re-connect the power plug and unlock the AC power switch. Chapter 5 How to Operate the Arizona 250 GT...

  • Page 65: How To Manage Print Jobs

    To do this click on the Windows Start button the select My Computer, My Network Places and ensure that the Arizona 250 GT is on the list. Install the Arizona 250 GT Printer Installation File on the ProductionHouse computer (if you have not already done this during the installation of the ProductionHouse software).
  • Page 66 [42] [42] Configure Printer Host Name Note: If you have more than one Arizona 250 GT printer, each printer must have a unique network name. The network name can be changed in the Settings module of the printer User Interface.
  • Page 67 How to Install the Onyx Printer Driver Check Configuration Click on Test to verify that the computer and printer are in communication. If the Test was successful, a verification message is displayed to indicate a Valid IP address was found. Correction If no valid IP address is found, check that the host name of the printer is correct and that port 9100 was selected.

  • Page 68: How To Set Up A Print Job

    How to Set Up a Print Job Introduction This section explains how to select an image to print on the Arizona 250 GT. The basic steps are outlined here and explained below. More detailed explanations for some of these steps are available (see ‘Print Job Control Module’...
  • Page 69 How to Set Up a Print Job Measure Media Thickness Use a digital slide caliper or micrometer to accurately measure the media thickness of the media. An error in measurement of media thickness will affect bi-directional alignment and can contribute to the amount of graininess in the printed image or cause a carriage/printhead crash with the media.
  • Page 70 Also it reduces the time it takes for the gantry to start the print. Chapter 5 How to Operate the Arizona 250 GT...

  • Page 71: How To Manage The Media Vacuum

    The Media Vacuum System Introduction The Arizona 250 GT uses a low-flow, high-vacuum system with three pre-set zones to secure rigid media for printing on the printer table. A fabricated aluminum overlay sheet placed on the surface of the table creates the vacuum field. The overlay sheet is pin-registered to the table.
  • Page 72 (3) Top Vacuum Zone Zone Zone [43] (4) Vacuum Bleed (5) Left Zone (6) Top Zone (7) Right Zone Valve Control Control Control [43] Imperial Vacuum Zones [44] [44] Metric Vacuum Zones Chapter 5 How to Operate the Arizona 250 GT...
  • Page 73 The Media Vacuum System [22] 1 - Bleed Valve partly 2 - Left Zone is Open open [45] 3 - Top Zone is 4 - Right Zone is Open Closed [45] Vacuum Zone Controls Vacuum Zone Control Handles Three vacuum zone control valves with handles are used to control which zones of the printer table will have vacuum applied when the table vacuum pump is turned on.
  • Page 74 To remove ink we recommend that you use a paint scraper containing a straight edge razor blade (these can be found at a local hardware store). Refer to the Maintenance section for more detailed instructions. Chapter 5 How to Operate the Arizona 250 GT...

  • Page 75: How To Create Custom Vacuum Zones

    How to Create Custom Vacuum Zones How to Create Custom Vacuum Zones Introduction A fabricated aluminum overlay sheet placed on the surface of the printer table is used to create a vacuum field that is divided into zones. When the printer is installed, three vacuum zones are available.
  • Page 76 > 20 inches of Hg. Also verify that the time it takes for the vacuum to establish is less than 4 seconds. Repeat step 6 for the all other zones individually. Chapter 5 How to Operate the Arizona 250 GT...

  • Page 77: How To Manage Media

    Océ Display Graphics Systems has conducted extensive testing of many media. Since the Arizona 250 GT printer is capable of imaging on a wide range of material, we encourage you to explore various media so that you can establish your own criteria for achieving high quality images in your work environment.
  • Page 78 It is particularly useful when printing on objects of unknown composition and for use in industrial applications. It is not available in all countries due to substance/transport restrictions. Chapter 5 How to Operate the Arizona 250 GT...
  • Page 79 How to Handle Media Thermal Expansion of Media When imaging on media that will expand when subjected to heat (e.g., styrene or Plexiglas, etc.), don’t wedge the media by butting other material against it as this may cause the media to buckle. Also if multiple pieces of the media are used, allow enough space between the pieces to allow for thermal expansion.

  • Page 80: Underlay Board To Reduce Artifacts

    Note: If you use the underlay board make sure that you cover over any areas of the board not covered by the media or the vacuum pressure will be reduced. Also make sure that there are no high spots that could cause a carriage collision. Chapter 5 How to Operate the Arizona 250 GT...
  • Page 81 Underlay Board to Reduce Artifacts Illustration [46] [46] Underlay Board with Media Tips On How to Use the Underlay Board: Use scrap pieces of media to cover any exposed area of the underlay board that the carriage will travel over. This prevents the board from lifting off the table and colliding with the carriage.
  • Page 82 Underlay Board to Reduce Artifacts Chapter 5 How to Operate the Arizona 250 GT...

  • Page 83: Ink System Management

    Chapter 6 Ink System Management...

  • Page 84: Arizona 250 Gt Ink

    Arizona 250 GT Ink Introduction The Arizona 250 GT uses UV-curable inks including Cyan, Magenta, Yellow, and Black. Due to the UV curing technology, the ink dries immediately and the printed material may be handled or cut directly after printing. The ink part numbers, which are necessary for ordering more ink, are provided in the table below.
  • Page 85 Arizona 250 GT Ink Ink temperature control is achieved by pumping a coolant fluid through the ink reservoir block and printheads. An internal thermostat on each printhead and one on the reservoir block provides temperature feedback. The condition of the printheads is maintained by periodic cleaning at the maintenance station on the gantry.
  • Page 86 UV Flush solution Ink Filters The Arizona 250 GT ink system is protected from contaminants in the ink by means of four ink filters. These are easily accessed and can be replaced by the end-user when they become blocked with debris. The expected average lifetime for a filter is approximately 6 months or 11 bags of ink (22 liters).
  • Page 87 Arizona 250 GT Ink Note: A loss of pigment when printing a nozzle check indicates that a filter is clogged and must be replaced. How to Store and Handle UV Ink To ensure good quality images and to extend the life of printheads in the Arizona 250 GT printer, it is important to have good UV ink management procedures.

  • Page 88: How To Change Ink Bags

    How to Change Ink Bags How to Change Ink Bags Introduction The ink is supplied to the printer in 2 liter bags. The bags have a non-spill coupler bonded into the top corner. When installing onto the printer, the bags are inverted and the quick connect couplers are pushed into their corresponding female coupling - opening up the flow path for the ink.
  • Page 89 How to Change Ink Bags Illustration [48] [48] Remove the Quick-Release Coupler How To Change an Ink Bag Attention: For Personal Safety, it is recommended that the operator wear rubber gloves, a protective apron, and safety glasses with side shields when handling inks.
  • Page 90 How to Change Ink Bags Chapter 6 Ink System Management...

  • Page 91: Error Handling And Troubleshooting

    Chapter 7 Error Handling and Troubleshooting...

  • Page 92: Troubleshooting Overview

    Troubleshooting Overview Troubleshooting Overview Introduction This section covers general problems that may occur with the printer. Malfunctions that trigger system error messages can be caused by human error, a system malfunction, an interface cable malfunction, mechanical printer malfunction and/or printer firmware failure. Definition Operator-recoverable Errors Operator-recoverable errors are problems that interfere with the print process but do...
  • Page 93 Troubleshooting Overview 3:= MORPE Maintenance Operator Recoverable Error Intervention can allow printer to continue. 5:= MRE Machine Recoverable Error Some intervention is required to allow printer to continue. Recycling power may recover. 7:= ORE Operator Recoverable Error Operator must do something or press a button to continue.
  • Page 94 Troubleshooting Overview Example 2 Drops of Ink Appear on the Media Check that the ink valves on top of the carriage are all open. If an ink valve is closed, there is no vacuum pressure to hold the ink and it will drip out of the printhead. If Problems Persist If problems persist, perform the following actions as appropriate for the situation: •...

  • Page 95: How To Improve Quality When Banding Occurs

    How To Improve Quality When Banding Occurs How To Improve Quality When Banding Occurs Introduction Banding can occur in an image for a number of reasons. Typically it occurs due to neighboring nozzles that do not fire or multiple nozzles that fire with poor directionality.
  • Page 96 How To Improve Quality When Banding Occurs Chapter 7 Error Handling and Troubleshooting...

  • Page 97: Printer Maintenance

    Chapter 8 Printer Maintenance...

  • Page 98: Maintenance Guidelines

    Maintenance Guidelines Maintenance Guidelines Introduction The Arizona 250 GT operator is responsible for the regular maintenance of the printer. This section provides detailed information about what is required for proper printer maintenance. While Océ Display Graphics Systems furnishes guidelines for periodic maintenance, the optimum maintenance schedule evolves from careful observation of your printer over a period of use.
  • Page 99 Maintenance Guidelines Operator Maintenance Schedule The Arizona 250 GT printer requires regular maintenance. Periodic cleaning should be scheduled for some components during the week. A few minutes spent cleaning ensures the highest quality prints. Several areas require maintenance to ensure the highest print quality, and the printer design gives you easy access to all these areas.

  • Page 100: Maintenance Procedures

    Printhead Maintenance Maintenance Procedures Printhead Maintenance Introduction The Maintenance Station is located below the carriage. Printhead Maintenance takes place while the carriage is parked. The station is covered by a sliding door that has an open grid in the center that allows any waste ink to drip down through the station and into the waste tray.
  • Page 101 Printhead Maintenance Before you begin Make sure the carriage is in the parked position. The carriage and gantry automatically return to this position after an image is printed. Do not move the carriage or gantry from this position as this will make it impossible to perform an ink purge.
  • Page 102 Printhead Maintenance Illustration [49] [49] Maintenance Station Switches How To Perform Maintenance Slide the cover out from under the carriage to reveal the maintenance station. Press and release switch 1 to initiate a purge. The carriage will lower to its purge height (4mm above the table surface).
  • Page 103 Printhead Maintenance Note: In the next step, start with the left printhead and work to the right as this limits the possibility that drops of ink will fall onto the coiled hose. Also, do not push up too hard on the printhead as you may dislodge it and this will require a service call to fix.
  • Page 104 Printhead Maintenance Maintenance for Select Printheads On the top of the carriage there are 4 hand-turnable ink valves. If you have performed a printhead maintenance and find that one or more printheads require additional maintenance, turn off the valves of all the other colors. Perform all of the steps for printhead maintenance again, but only on the affected printheads.

  • Page 105: Remove Ink From The Table

    Remove Ink From the Table Remove Ink From the Table Introduction How often you need to perform these procedures will vary, depending on printer usage and work habits. Remove Ink from Table Clean ink from the table whenever necessary. Once UV ink is cured, the best method for removing it from the table is to use the provided scraper (it is also possible to achieve good results with a razor blade that is set into a handle/holder).

  • Page 106: Empty The Ink Waste Tray

    Empty the Ink Waste Tray Empty the Ink Waste Tray Introduction The waste tray is located below the Maintenance Station. It accumulates ink that has dripped from the printheads or ink waste that results from a purge when performing Printhead Maintenance or Swabbing the Printheads. The ink drops onto a sloped drain plate at the base of the Maintenance Station and drains from there into the waste tray.
  • Page 107 Empty the Ink Waste Tray How to Empty the Waste Tray Put a cloth or paper towel in place on the floor to catch any drips while the tray is emptied. Place a suitable empty container that holds at least 1 liter under the waste tray drain. [53] [53] Waste Tray Valve Turn the valve on the waste tray until it starts to drain the waste material.

  • Page 108: Swab Printheads

    Swab Printheads Swab Printheads Introduction To ensure optimal print quality, it is important to periodically clean the printheads with a swab to remove any excess ink or any debris that was not removed by Printhead Maintenance. When to do At the end of each week, clean the printhead nozzle plates using the swabbing procedure.
  • Page 109 Swab Printheads Attention: Never "scrub" the printhead with a swab as this will drag debris into other nozzles. Always slowly move the swab across the printhead with the swab at an angle and not perpendicular to the printhead. Never use Isopropyl alcohol to clean the printheads. Do not allow swabs to be contaminated with any dust or dirt prior to use.
  • Page 110 Swab Printheads Run a Nozzle Check print or an image test print and verify that all nozzles are firing properly. Note: If the problem persists, you can swab multiple times. Use a new clean side of the swab each time (this means a maximum of two swipes per swab). It is possible that as many as ten swipes can be required.

  • Page 111: Clean Carriage Underside

    Clean Carriage Underside Clean Carriage Underside Introduction To maintain optimal print quality, it is important to periodically clean the underside of the carriage to remove any excess ink. If the buildup of ink is excessive, it can be transferred to media and thus reduce print quality. When to do At the end of each week, or as needed, clean any ink that has accumulated on the underside of the carriage.
  • Page 112 Clean Carriage Underside Illustration [54] [54] Ink Removal Technique How to Clean the Carriage Underside Slide the maintenance station cover plate out from under the carriage to reveal the maintenance station. Press switch 2 to raise the carriage to its maximum height. Wrap a clean poly wipe cloth around your index finger.

  • Page 113: Clean Uv Lamp Filters

    Clean UV Lamp Filters Clean UV Lamp Filters Introduction The top of the assemblies that house the left and right UV lamp cartidges contains a filter that can cause overheating of the lamps if it becomes clogged with dust or debris.

  • Page 114: Fill The Coolant Reservoir

    Fill the Coolant Reservoir Fill the Coolant Reservoir Introduction The coolant is a thermal fluid used to maintain the temperature of the ink in the printheads and ink reservoirs on the carriage. Temperature control of the ink is required in order to achieve the correct ink viscosity, which affects the jetting velocity of the ink and thus the quality of printed images.
  • Page 115 Fill the Coolant Reservoir Illustration [55] [55] Fill Coolant Reservoir Fill the Coolant Reservoir Open the container of coolant fluid. Insert the syringe into the fluid and draw back the plunger until the syringe is almost full (leave a small amount of air so that you can expel it at the end to avoid fluid dripping from the fill nozzle.

  • Page 116: Clean Gantry Rails

    Clean Gantry Rails Clean Gantry Rails Introduction Dust and debris can accumulate on the gantry rails, which run along the length of the table. The bearings that run on the rails are equipped with shields that are designed to keep debris from entering the bearing housing. After a period of time and use, debris can accumulate on the outside of the bearing shields as the gantry traverses the table.

  • Page 117: Change Ink Filters

    Change Ink Filters Change Ink Filters Introduction Each ink color has a filter that removes any particulate matter from the ink as it is pumped from the ink bag toward the printheads. The ink filters are located at the electronics end of the printer around the corner from the ink bags. When to do The ink filter for a particular color of ink must be replaced after 11 bags of that ink have been consumed.
  • Page 118 Change Ink Filters Procedure to Change an Ink Filter Open the sliding maintenance station door to disable ink pumps. Remove the two screws that hold the ink filter enclosure cover in place (thumbscrews can be loosened by hand or use a Philips screwdriver if they are too tight). Use a lint-free cloth to catch ink, and place it below the bleed valve at the bottom of the filter.

  • Page 119: How To Change A Uv Lamp

    How to Change a UV Lamp Introduction The Arizona 250 GT uses two (2) UV lamps, one on each side of the carriage, to instantly cure the ink during printing. These UV lamps have an expected life of 500 hours and must be replaced by the user when they fail or can no longer cure the ink at maximum available power.
  • Page 120 How to Change a UV Lamp Illustration [58] [58] Remove UV Lamp Cartridge How to Replace a UV Lamp Cartridge Turn off the AC power and lockout the printer. Remove the carriage guard by lifting it straight up and then away from the carriage. Use a 3mm allan key to loosen the screw at the top of the cartridge with the lamp that needs to be replaced.

  • Page 121: Print A Nozzle Check

    Print a Nozzle Check Print a Nozzle Check Introduction The Nozzle Check print fires each nozzle individually in a manner that allows clogged nozzles to be easily identified by a visual inspection of the printed image. The Nozzle Check print consists of the following elements: Print Identification - Océ...
  • Page 122 Print a Nozzle Check Required tools Blue LED view light (sometimes needed to enhance contrast in the Yellow area). Océ I/O paper Note: Usually, two or more Nozzle Checks will be printed to verify that nozzle issues are resolved. To calculate the required offset when you print multiple consecutive nozzle checks, add a horizontal offset of 2.5"...
  • Page 123 Print a Nozzle Check Result When a printhead does not have any dropouts, it will look the Nozzle Check print of the black (K) section illustrated below. Note: There is an indication of some poor directionality in one of the nozzles illustrated in the top left section of the sample below, but it will not affect image quality (although it could, if multiple adjacent nozzles show this problem).
  • Page 124 Print a Nozzle Check Chapter 8 Printer Maintenance...

  • Page 125: Application Hints And Tips

    Appendix A Application Hints and Tips...

  • Page 126: Hints And Tips

    GT printer. They are offered as starting points or suggestions for dealing with various situations. Since this information is subject to change please check our web site at http://www.dgs.oce.com/PrinterSupport/Arizona250GT_Customer/ for the current list of "Application Hints and Tips". The hints are tips are grouped into three categories: Maintenance, Printing, and Color and Profiling.
  • Page 127 Hints and Tips Printing Hints and Tips [26] Situation Hint and Tips Maximizing To maximize printer throughput, orient jobs so that the long Throughput side of the image to be printed is oriented in the direction of carriage travel. Also, if possible nest multiple jobs in Produc- tionHouse to be printed on either a single or multiple pieces of media at the same time.
  • Page 128 2) Then select Center Horizontal. 3) Print the image, then flip the media and print the backside. Imaging with The Arizona 250 GT is capable of printing full bleed images, Bleed i.e. images printed slightly larger than the media size to en- sure that the printed images goes to the all the way to media edges.
  • Page 129 [27] Situation Hint and Tips Setting Ink Restric- The Arizona 250 GT uses greyscale variable drop size tech- tions nology. Some of the larger drop sizes are not allowed for a particular print mode. When settings restrictions ensure the following drop sizes are set to zero for the following print modes: Production &...
  • Page 130 Hints and Tips Situation Hint and Tips Long USB Cable We recommend that you purchase a 16' USB cable (maxi- for Eye-One Spec- mum USB cable length spec.) or a 10' USB cable extension trophotometer for use with the Eye-One Spectrophotometer. Exporting Spectro- When making a media model (linearization) or ICC profile photometer Read-...
  • Page 131 Index Index Ink Filters ......42 AC power ......61 AC power plug .
  • Page 132 Index Reduce Artifacts ......80 safety interlock system ....24 Safety Labels .

Table of Contents
