Executing the inspection
- The "Column" field defines the horizontal position of the text overlay.
- The "Line" field defines the vertical position of the text overlay.
- "Foreground" defines the font color.
- "Background" defines the color that surrounds the text.
- The button next to the "Visibility" item defines whether the inspection text is shown or hidden.
• Confirm this dialog with OK.

Configure System Texts

You can access the settings for your system texts, such as headers or data overlays directly from the inspection view. A precise description of the
setting possibilities is described under System settings/system texts on Seite 42.

Clear Custom Texts

Select this function to delete all custom texts from the video view. The texts will only be cleared, they will not be deleted in the text settings. You
can overlay these texts again by activating the check box with the designation "Visible" in the "Custom Texts" dialog.
98
iPEK International GmbH
Header 1
See, Gewerbepark 22, D-87477 Sulzberg
Header 2
Tel. +498376921800, FAX: +4983769218021
Header 3
Freetexts
Column
1970-01-01
Data displays
1000 mbar
Data displays
e-mail:ISG_info@idexcorp.com Internet:www.ipek.at
Footer
Freetext
00:00:01
0.00 m 0 g
Fig. Text positions
Line
0 g 0 gC
Text Menu
