Buttons

Certain functions are identical in all measurements in order to make control clear and easy for your inspection. This includes the options of individu-
ally setting the setting and measuring lines as well as fonts or adjusting the 3D grid unit and its lines. Buttons are activated by pressing them and
deactivated by pressing them again.
Set color scheme
This function allows you to adjust the setting and measuring lines as well as texts to your inspection environment
in terms of color.
Settings
This function allows you to set the 3D grid for the 3-dimensional visualization of the pipe
and load an inspection image, which you can then measure.
Close view
You can quit the respective dialogue and return to the main overview,
or return to the event with this function.
Direct entry referencing virtual pipe / real pipe
This button is used to skip directly to the referencing default settings.
This button is available in all measurements, as it forms the basis of every measurement.
Direct entry branch measurement
This button is used to skip directly to the branch measurement.
Direct entry bend measurement
This button is used to skip directly to the bend measurement.
Direct entry water level measurement
This button is used to skip directly to the water level measurement.
Direct entry pipe wall object measurement
This button is used to skip directly to the wall object measurement.
Direct entry cross-section object measurement
This button is used to skip directly to the cross-section object measurement.
